Directed Directechs DS4+ Installation Manual page 39

Wire Information
Function Color
Ford F450 2008-2010
RX Violet/Gray
TX Yellow/Orange
12V Blue/Red or
White/Violet
Ignition White/Orange
Starter Blue/White
Accessory Brown/Yellow or
Yellow/Orange
Keysense Blue/Gray
Parking Lights Violet/White
HS CAN High White/Lt. Green or
White/Blue
HS CAN Low Pink/Lt. Green or
White
Hood Trigger Blue/Orange
Driver Door Trigger Green/Violet
Passenger Front Door Trigger White
Driver Rear Door Trigger Green
Passenger Rear Door Trigger Yellow
Lock Blue/Green
Unlock Yellow/Violet
Brake Violet/White
Ford F450 2011
RX Violet/Gray
TX Yellow/Orange
12V Blue/Red or
Green/Red
Ignition White/Orange
Starter Blue/White
Accessory Violet/Green
Keysense Blue/Gray
Parking Lights Yellow/Blue
HS CAN High White/Blue
HS CAN Low White
Hood Trigger Blue/Orange
Driver Door Trigger Green/Violet
Passenger Front Door Trigger White
Driver Rear Door Trigger Green
Passenger Rear Door Trigger Yellow
Lock Blue/Green
Unlock Yellow/Violet
Brake Violet/White
39
Pin Polarity Location
4 Data (PATS) connector Type 4.
3 Data (PATS) connector Type 4.
8 (+) Ignition switch.
1 (+) Ignition switch.
10 (+) Ignition switch.
7 (+) Ignition switch.
3 (+) Ignition switch.
6 (+) SJB (Smart Junction Box) passenger kick panel.
6 Data OBDII.
14 Data OBDII.
10 (-) SJB passenger kick panel.
14 N. Closed Driver kick panel or SJB passenger kick panel.
2 N. Closed SJB passenger kick panel.
Required ONLY when enabling the security features during
3 N. Closed
module flashing.
15 N. Closed
See Tech Tip 1921 at www.directechs.com.
17 (-) Driver kick panel or SJB passenger kick panel.
4 (-) Driver kick panel or SJB passenger kick panel.
40 (+) Brake switch or SJB passenger kick panel.
4 Data (PATS) connector Type 4.
3 Data (PATS) connector Type 4.
4 (+) Ignition switch.
1 (+) Ignition switch.
7 (+) Ignition switch.
6 (+) Ignition switch.
5 (+) Ignition switch.
6 (+) Driver kick panel or SJB (Smart Junction Box) passenger kick
panel.
6 Data OBDII.
14 Data OBDII.
2 N. Closed SJB passenger kick panel.
9 N. Closed SJB passenger kick panel.
5 N. Closed SJB passenger kick panel.
Required ONLY when enabling the security features during
20 N. Closed
module flashing.
21 N. Closed
See Tech Tip 1921 at www.directechs.com.
6 (-) Driver kick panel or SJB passenger kick panel.
8 (-) Driver kick panel or SJB passenger kick panel.
28 (+) Brake switch or SJB passenger kick panel.
Connector Information
Color
Black
Black
Gray
Gray
Gray
Gray
Gray
Gray
Black
Black
Black
Gray
Gray
Gray
Gray
Gray
Gray
Black
Black
Black
Black
Black
Black
Black
Black
Gray
Black
Black
Green
Black
Black
Black
Black
Black
Black
Black
© 2018-01-12 Directed. All rights reserved.
Pins Ref.
4 A
4 A
10 B
10 B
10 B
10 B
10 B
13 P
16 C
16 C
26 P
26 P
26 P
26 P
26 P
26 P
26 P
52 P
4 A
4 A
7 B
7 B
7 B
7 B
7 B
10 P
16 C
16 C
26 P
26 P
26 P
26 P
26 P
26 P
26 P
52 P
DS4+ FORD1
