Directed Directechs DS4+ Installation Manual page 42

Wire Information
Function Color
Ford Fusion 2006-2012
Brake Violet/White
RX Violet/Gray
TX Yellow/Orange
12V Brown/Red
Ignition White/Orange
Starter Blue/White
Accessory Violet/Green
Keysense Blue/Gray
HS CAN High White/Blue
HS CAN Low White
Parking Lights Gray/Yellow
Hood Trigger Blue/Orange
Driver Door Trigger Green/Violet
Lock Gray/Yellow
Unlock Violet/Gray
Factory Disarm Violet/Brown
Trunk Release Brown
Passenger Front Door Trigger White
Driver Rear Door Trigger Green
Passenger Rear Door Trigger Yellow
Ford Mustang 2005-2007
RX Gray/Orange
TX White/Lt. Green
12V Red
Ignition White/Yellow
Starter Dark Green
Accessory Black/Pink
Keysense Lt. Green/Violet
Parking Lights Black/Lt. Green
Parking Lights Ground Black
HS CAN High White/Lt. Green
HS CAN Low Pink/Lt. Green
Driver Door Trigger Lt. Green/Black
Lock White/Violet
Unlock Blue/Green
Factory Disarm Lt. Blue/Black
Hood Trigger Violet/Orange
Brake Lt. Green
Trunk Release White/Violet
Passenger Door Trigger White
42
Pin Polarity Location
4 (+) Brake pedal switch.
4 Data (PATS) connector Type 4.
3 Data (PATS) connector Type 4..
4 (+) Ignition switch.
1 (+) Ignition switch.
7 (+) Ignition switch.
6 (+) Ignition switch.
5 (+) Ignition switch.
6 Data OBDII.
14 Data OBDII.
32 (+) Drivers SJB (Smart Junction Box) or drivers kick panel.
27 N. Closed Drivers SJB.
11 N. Closed Drivers SJB or drivers kick panel.
4 (-) Drivers SJB or drivers kick panel.
10 (-) Drivers SJB or drivers kick panel.
5 (-) Drivers SJB or drivers kick panel.
27 (-) Drivers SJB or trunk release switch.
12 N. Closed Drivers SJB.
Required ONLY when enabling the security features during
8 N. Closed
module flashing.
7 N. Closed
See Tech Tip 1921 at www.directechs.com.
3 Data (PATS) connector Type 4.
4 Data (PATS) connector Type 4..
4 (+) Ignition switch.
1 (+) Ignition switch.
7 (+) Ignition switch.
6 (+) Ignition switch.
5 (+) Ignition switch.
5 (-) Headlight switch.
See Tech Tip 1096 at ww.directechs.com
7 Cut
6 Data OBDII.
14 Data OBDII.
2 N. Closed Passenger SJB (Smart Junction Box) or drivers kick.
3 (-) Passenger SJB or drivers kick.
1 (-) Passenger SJB or drivers kick.
9 (-) Passenger SJB or drivers kick.
15 N. Closed Passenger SJB.
16 (+) Passenger SJB or brake switch.
13 (-) Passenger SJB or trunk release switch.
2 N. Closed Passenger SJB or drivers kick.
Required ONLY when enabling the security features during
module flashing.
See Tech Tip 1921 at www.directechs.com.
Connector Information
Color
White
Green
Green
Black
Black
Black
Black
Black
Black
Black
Tan
Tan
Black
Black
Black
Black
Black
Black
Black
Black
Black
Black
Black
Black
Black
Black
Black
Brown
Brown
Black
Black
Black
Black
Black
Black
Black
Gray
Black
Black
© 2018-01-12 Directed. All rights reserved.
Pins Ref.
4 K
4 A
4 A
7 B
7 B
7 B
7 B
7 B
16 C
16 C
32 D
32 D
32 D
32 D
32 D
32 D
32 D
32 D
32 D
32 D
4 A
4 A
7 B
7 B
7 B
7 B
7 B
10 H
10 H
16 C
16 C
26 P
26 P
26 P
26 P
52 P
36 P
52 P
26 P
DS4+ FORD1
