Directed Directechs DS4+ Installation Manual page 46

Wire Information
Function Color
Lincoln LS 2002-2006
Orange/Yellow or
Brake
Orange/Blue
RX Gray/Red
TX White/Red
12V Red
Ignition Green/Black
Starter Gray/Black
Accessory 1 Pink/Yellow
Accessory 2 Pink/White
Keysense Red/White
Hood Trigger White
HS CAN High - (2003-2006) Gray/Red
HS CAN Low - (2003-2006) Blue/Red
Arm/Lock Black/Blue
Disarm/Unlock (double pulse) Black/White
Driver Door Trigger Black/Yellow
Trunk Release White
Parking Lights Headlight switch. See Tech Tip 1095 at www.directechs.com
Passenger Front Door Trigger Black/Blue
Driver Rear Door Trigger Black/Red
Passenger Rear Door Trigger Black/Green
Lincoln MKS 2009-2012
RX Yellow/Orange
TX Violet/Gray
Power Lift gate Gray/Yellow
12V Blue/Red
Ignition White/Orange
Starter Blue/White
Accessory Violet/Green
Keysense Blue/Gray
HS CAN High White/Blue
HS CAN Low White
Lock Gray/Yellow
Unlock Violet/Gray
Factory Disarm Violet/Brown
Driver Door Trigger Green/Violet
Hood Trigger Blue/Orange
Brake Violet/White
Parking Lights Violet/White
Passenger Front Door Trigger White
Driver Rear Door Trigger Green
Passenger Rear Door Trigger Yellow
46
Pin Polarity Location
2 (+) Brake pedal switch.
4 Data (PATS) connector Type 4.
3 Data (PATS) connector Type 4..
8 (+) Ignition switch.
4 (+) Ignition switch.
2 (+) Ignition switch.
5 (+) Ignition switch.
1 (+) Ignition switch.
7 (+) Ignition switch.
3 N. Closed FEM (Front Electronic Module) in driver kick panel.
6 Data OBDII.
14 Data OBDII.
16 (-) The DDM (Driver Door Module) is located in the driver door.
17 (-) The DDM is located in the driver door.
8 Cut FEM in driver kick panel.
4 (-) FEM in driver kick panel.
FEM in driver kick panel.
Required ONLY when enabling the security features during
15 N. Closed
module flashing.
See Tech Tip 1921 at www.directechs.com.
16 N. Closed REM (Rear Electronic Module) in trunk above battery.
Required ONLY when enabling the security features during
module flashing.
17 N. Closed
See Tech Tip 1921 at www.directechs.com.
4 Data (PATS) connector Type 4.
3 Data (PATS) connector Type 4..
5 (-) Power lift gate switch.
4 (+) Ignition switch.
1 (+) Ignition switch.
7 (+) Ignition switch.
6 (+) Ignition switch.
5 (+) Ignition switch.
6 Data OBDII.
14 Data OBDII.
17 (-) Drivers SJB (Smart Junction Box) or drivers kick.
4 (-) Drivers SJB or drivers kick.
8 (-) Drivers SJB or drivers kick.
14 N. Closed Drivers SJB or drivers kick.
10 N. Closed Drivers SJB or hood switch.
3 (+) Brake switch or junction connector left of steering column.
20 (+) Drivers SJB or drivers kick.
2 N. Closed Drivers SJB or drivers kick.
Required ONLY when enabling the security features during
3 N. Closed
module flashing.
15 N. Closed
See Tech Tip 1921 at www.directechs.com.
Connector Information
Color
Green
Green
Green
Black
Black
Black
Black
Black
Black
Black
Black
Black
Black
Black
Black
White
White
White
Black
Black
Black
Black
Black
Black
Black
Black
Black
Black
Black
Gray
Gray
Gray
Gray
Black
Black
Black
Gray
Gray
Gray
© 2018-01-12 Directed. All rights reserved.
Pins Ref.
2 K
4 A
4 A
8 B
8 B
8 B
8 B
8 B
8 B
12 F
16 C
16 C
20 O
20 O
20 F
26 F
H
26 F
26 Q
20 Q
4 A
4 A
5 R
7 B
7 B
7 B
7 B
7 B
16 C
16 C
26 D
26 D
26 D
26 D
26 D
30 K
32 D
26 D
26 D
26 D
DS4+ FORD1
