Contents Introduction Vehicle function compatibilities Pre-installation and application warnings Installation Wiring diagram with T-Harness (THTON7) Wiring diagram Locating components in the vehicle Vehicle connections Module programming For Security-Onlyand Convenience-Only programming, see next section. Module programming for convenience only (skip transponder) Module programming for security-only installations Pairing remotes Connecting the module...
Introduction This guide provides information on the installation of the DS3/DS3+ and DS4/DS4+ modules as a digital solution. Using these modules in a digital configuration require the module to be flashed with vehicle specific firmware. Refer to our website (www.directechs.com) and click on the DIRECTLINK text in the header for additional information.
Vehicle function compatibilities This section lists all the functions compatible with this vehicle for the installation illustrated in this guide. Note: The telematics features listed below (with an asterisk) ONLY apply when using SmartStart. Auto Headlamp Shutoff Remote Start Takeover Parking Lights Control SmartStart Arm Factory Security...
Pre-installation and application warnings This section highlights important information for this specific firmware and will assist in pricing accordingly, as START HERE well as bringing awareness to any operational or vehicle limitations. Compatibilities and Requirements T-Harness Keys required for Keys required THTON7 programming for operation...
Wiring diagram with T-Harness (THTON7) Refer to "Pre-installation and application warnings" for important information, such as the description of each special note referenced in the diagram ( NOT USED Connect the connector labeled Type A. Body ECU Headlight Switch Body ECU Connector (middle conn.
Wiring diagram Refer to "Pre-installation and application warnings" for important information, such as the description of each special note referenced in the diagram ( Body ECU Connector HS CAN High: HS CAN Low: Tan, pin 5 White, pin 4 Body ECU Connector (lower conn.
Locating components in the vehicle Optional starter disable connection When using an external relay, use a 1N4002 diode or larger. 1A diode [1N4002+ ] (+) Ignition (-) Ground When Armed (GWA) Output: Blue/White: 2 Refer to the Vehicle connections section for wire and Starter (conn.
Vehicle connections The connection information listed below is specific to the 2023 Toyota Camry. Refer to “Pre-installation and application warnings” for a list of important notes. Data harness, 8-pin white connector (H1) Module Connects To Conn./Pin Color Description Wire Location (+/-) Wire Color Connection...
Page 10
Module Connects To Conn./Pin Color Description Wire Location (+/-) Wire Color Connection H2/17 Black/White No Connection No Connection H2/18 Orange/Black No Connection No Connection H2/19 Blue No Connection No Connection H2/20 Green No Connection No Connection H2/21 Gray The installation of an aftermarket hood pin is only required on vehicles (-) Hood Switch Input that are not equipped with a factory hood pin, or if not supported in data.
Page 11
Module Connects To Conn./Pin Color Description Wire Location (+/-) Wire Color Connection H4/6 Green No Connection No Connection H4/7 Violet No Connection No Connection H4/8 Orange No Connection No Connection H4/9 Red/White No Connection No Connection H4/10 Pink No Connection No Connection RF Port harness, 2-pin white connector (H5) Module...
Module programming Refer to “LED diagnostics and troubleshooting” for more information and for troubleshooting purposes. Security-Only and Convenience-Only programming, see next section. Note: The master key is required to complete the module programming successfully. Ensure vehicle is in a safe location and cannot move forward during programming. For vehicles equipped with a manual transmission, make sure the gearshift lever is in the neutral position.
Module programming for convenience features only (skip transponder) Refer to "LED diagnostics and troubleshooting" for more information and for troubleshooting purposes. Ensure vehicle is in a safe location and cannot move forward during programming. For vehicles equipped with a manual transmission, make sure the gearshift is in the neutral position. Connect the 12-pin main power harness to the module.
Module programming for security-only installations Refer to "LED diagnostics and troubleshooting" for more information and for troubleshooting purposes. Ensure vehicle is in a safe location and cannot move forward during programming. For vehicles equipped with a manual transmission, make sure the gearshift is in the neutral position. Connect the 12-pin main power harness to the module.
When used in conjunction with Directed SmartStart ® To enable D2D communication between the DS3+/DS4+ and the Directed SmartStart one of the following actions must be performed ® before providing power to the Directed SmartStart unit: ®...
DO NOT connect the Directed SmartStart 2-pin power harness when using the DS3+/DS4+. Power and ground will be provided by the ® D2D connector on the module. Refer to the Directed SmartStart documentation for further details. ® D2D port configuration Caution! Do not connect the Control Center (antenna) or any digital sensors (8504D) to the white D2D1 port.
Manual Transmission IMPORTANT! Directed does not approve nor support installations of manual transmission and remote starts on any electronic vehicles (EV), OEM Remote Start Activation firmware, vehicles with convertibles and/or removable tops, including but not limited to Jeep Wrangler, Honda S2000, Mazda Miata, and other such vehicles.
LED diagnostics and troubleshooting This section provides LED diagnostics and troubleshooting information to guide you through the various stages of your installation. Module Programming Description Troubleshooting Make sure the D2D harness is connected and that 12 Volt is present between the red and black wires. If Module has no power.
Page 19
External Module Synchronization Description Troubleshooting OBDII feature not supported. The diagnostic data bus was not detected, therefore the SmartStart features will be limited. (Flashes red, red, then orange) x 10 Active Ground When Running (Status) Description Troubleshooting Ground When Running (Status) command The module has initialized the remote start sequence.
Soft reset A module reset will only erase the steps perfomed in “Module Programming”. The firmware and settings flashed to the module will not be affected. Connect all but the If required for your installation, connect all the harnesses to the module, EXCEPT the 12-pin main 12-pin harness power harness.
Tach learning procedure (not needed with Virtual Tach) Data Tach: The procedure is not required as the tach comes preprogrammed. However, it is strongly recommended to learn the exact value of the vehicle for the most consistent and reliable starting and functionality. Hardwired Tach: The procedure is required.
Limited Lifetime Consumer Warranty VOXX DEI LLC (the Company) warrants to the original purchaser of this product that should this product or any part thereof, under normal use and conditions, be proven defective in material or work- manship within the Lifetime from the date of original purchase in the original vehicle, such defect(s) will be repaired or replaced with new or reconditioned product, (at the Company’s option) without charge for parts or repair labor.
3 possible ways you can send commands to your vehicle, using the: in Park (P). • Factory remote. • Aftermarket remote. Press the Remote Start button on the transmitter.* • Directed SmartStart application via your smartphone. & Parking lights The parking lights will flash once to indicate the vehicle is Press...
Page 24
The application enables a “Cloud-Connected Car” like never before, providing 2-way interaction with your vehicle. Connectivity is managed through the Directed Cloud Services (DCS) network linking car, app, end user, and the Internet.
