Directed Directechs DS4+ Installation Manual page 18

Wire Information
Function Color
Ford Taurus 2000-2001
RX Red/Black
TX Brown/Orange
Parking Lights Brown
12V Lt. Green/Violet
Ignition Red/Lt. Green
Starter Red/Lt. Blue
Accessory 1 Gray/Yellow
Accessory 2 Black/Lt. Green
Keysense Black/Pink
Hood Trigger Tan/Lt. Green
Driver Door Trigger Yellow/Black
Lock Pink/Yellow
Unlock Pink/Lt. Green
Trunk Release (with Keyless) Violet/Yellow
Trunk Release (w/o Keyless) Gray/Red
Brake Red/Lt. Green
Passenger Door Triggers Gray/Red
Driver Rear Door Trigger Lt. Green/Yellow
Passenger Rear Door Trigger Pink/Lt. Blue
HS CAN High N/A
HS CAN Low N/A
Ford Taurus 2002-2005
RX Gray/Orange or
Brown/Yellow
TX White/Lt. Green or
Gray/Red
Parking Lights Brown
12V Lt. Green/Violet
Ignition Red/Lt. Green
Starter Red/Lt. Blue
Accessory 1 Gray/Yellow
Accessory 2 Black/Lt. Green
HS CAN High - (2004-2005) White/Orange
HS CAN Low - (2004-2005) Pink/Orange
Keysense Black/Pink
Hood Trigger Tan/Lt. Green
Driver Door Trigger Yellow/Black
Lock Pink/Yellow
Unlock Pink/Lt. Green
Trunk Release Violet/Yellow
Brake Red/Lt. Green
Passenger Door Triggers Gray/Red
Driver Rear Door Trigger Lt. Green/Yellow
Passenger Rear Door Trigger Pink/Lt. Blue
18
Pin Polarity Location
3 Data (PATS) connector Type 3.
4 Data (PATS) connector Type 3.
12 (-) Headlight switch or fuse box.
A4 (+) Ignition switch.
A2 (+) Ignition switch.
STA (+) Ignition switch.
A4 (+) Ignition switch.
A2 (+) Ignition switch.
(-) Ignition switch.
17 (-) GEM (Generic Electronic Module) left of steering column.
5 (-) GEM left of steering column.
18 (-) GEM left of steering column.
6 (-) GEM left of steering column.
26 (-) GEM left of steering column or trunk release switch.
26 (+) Trunk release switch.
1 or 2 (+) Brake pedal switch.
19 (-)
GEM left of steering column. Required ONLY when enabling the
20 (-)
security features during module flashing.
7 (-)
N/A N/A N/A
N/A N/A N/A
3 Data (PATS) connector Type 3.
4 Data (PATS) connector Type 3.
12 (+) Headlight switch or fuse box.
B3 (+) Ignition switch.
I1 (+) Ignition switch.
STA (+) Ignition switch.
A4 (+) Ignition switch.
A2 (+) Ignition switch.
6 Data OBDII.
14 Data OBDII.
17 (-)
17 (-)
5 (-)
GEM (Generic Electronic Module) left of steering column.
18 (-)
6 (-)
3 (-)
1 or 2 (+) Brake pedal switch.
19 (-)
GEM left of steering column. Required ONLY when enabling the
20 (-)
security features during module flashing.
7 (-)
Connector Information
Color
N/A
N/A
Gray
Black
Black
Black
Black
Black
Black
White
White
White
White
White
N/A
Black
White
White
White
N/A
N/A
N/A
N/A
Gray
Black
Black
Black
Black
Black
Black
Black
Black
White
White
White
White
White
Black
White
White
White
© 2018-01-12 Directed. All rights reserved.
Pins Ref.
4 A
4 A
12 F
15 B
15 B
15 B
15 B
15 B
15 B
26 J
26 J
26 J
26 J
26 J
N/A I
N/A D
26 J
26 J
26 J
N/A N/A
N/A N/A
4 A
4 A
12 F
15 B
15 B
15 B
15 B
15 B
16 L
16 L
20 J
26 J
26 J
26 J
26 J
26 J
N/A D
26 J
26 J
26 J
DS4+ FORD1
