Directed Directechs DS4+ Installation Manual page 33

Wire Information
Function Color
Ford Expedition 2003-2006
RX Gray/Orange
TX White/Lt. Green
Brake Lt. Green
12V Lt. Green/Violet
Ignition Dk. Blue/Lt. Green
Starter Red/LT. Blue
Accessory Black/Lt. Green
Keysense Black/Pink
Parking Lights Brown
Lock Pink/Yellow
Unlock Pink/Lt. Green
Trunk/Hatch Release White/Violet
HS CAN High - (2005-2006) White/Lt. Blue
HS CAN Low - (2005-2006) Pink/Lt. Blue
Driver Door Trigger Black/yellow
Passenger Door Trigger Black/Pink
Driver Rear Door Trigger Green
Passenger Rear Door Trigger Yellow
Ford Expedition 2007-2011
RX Blue/Gray
TX Violet/Brown
12V Blue/Red
Ignition White/Orange
Starter Blue/White
Accessory 1 Brown/Yellow
Accessory 2 Violet/Green
Keysense Blue/Gray
Parking Lights Violet/White
HS CAN High White/Blue
HS CAN Low White
Driver Door Trigger Green/Violet
Lock White/Brown
Unlock Blue/Brown
Trunk/Hatch Release Brown
Brake Yellow/Gray
Passenger Front Door Trigger White
Driver Rear Door Trigger Green
Passenger Rear Door Trigger Yellow
33
Pin Polarity Location
4 Data (PATS) connector Type 2.
3 Data (PATS) connector Type 2..
2 (+) Trailer connector under drivers dash.
4 (+) Ignition switch.
1 (+) Ignition switch.
7 (+) Ignition switch.
6 (+) Ignition switch.
5 (+) Ignition switch.
2 (-) Headlight switch or VSM (Vehicle Security Module) high in the
passenger kick panel
3 (-) VSM high in the passenger kick panel or driver kick panel.
2 (-) VSM high in the passenger kick panel or driver kick panel.
11 (-) VSM is high in the passenger kick panel.
6 Data OBDII.
14 Data OBDII.
4 N. Closed VSM high in the passenger kick panel or driver kick panel.
5 N. Closed VSM high in the passenger kick panel.
Required ONLY when enabling the security features during
11 N. Closed
module flashing.
6 N. Closed
See Tech Tip 1921 at www.directechs.com.
4 Data (PATS) connector Type 4.
3 Data (PATS) connector Type 4.
9 (+) Ignition switch.
1 (+) Ignition switch.
10 (+) Ignition switch.
7 (+) Ignition switch.
5 (+) Ignition switch.
3 (+) Ignition switch.
6 (+) SJB (Smart Junction Box) passenger kick panel or driver kick
panel.
6 Data OBDII.
14 Data OBDII.
14 N. Closed SJB passenger kick panel or driver kick panel.
17 (-) SJB passenger kick panel or driver kick panel.
4 (-) SJB passenger kick panel or driver kick panel.
7 (-) SJB passenger kick panel.
40 (+) SJB passenger kick panel or brake switch.
2 N. Closed SJB passenger kick panel.
Required ONLY when enabling the security features during
3 N. Closed
module flashing.
15 N. Closed
See Tech Tip 1921 at www.directechs.com.
Connector Information
Color
Green
Green
Gray
Black
Black
Black
Black
Black
Gray
Gray
Gray
Blue
Black
Black
Gray
Gray
Gray
Gray
Black
Black
Gray
Gray
Gray
Gray
Gray
Gray
Gray
Black
Black
Gray
Gray
Gray
Gray
Black
Gray
Gray
Gray
© 2018-01-12 Directed. All rights reserved.
Pins Ref.
4 A
4 A
6 D
7 B
7 B
7 B
7 B
7 B
12 H
14 E
14 E
14 E
16 C
16 C
26 E
26 E
26 E
26 E
4 A
4 A
10 B
10 B
10 B
10 B
10 B
10 B
13 P
16 C
16 C
26 P
26 P
26 P
26 P
52 P
26 P
26 P
26 P
DS4+ FORD1
