Directed Directechs DS4+ Installation Manual page 44

Wire Information
Function Color
Ford Taurus 2006-2007
Brake Red/Lt. Green
RX Gray/Orange
TX White/Lt. Green
Parking Lights Brown
12V Lt. Green/Violet
Ignition Red/Lt. Green
Starter Red/Lt. Blue
Accessory 1 Gray/Yellow
Accessory 2 Black/Lt. Green
HS CAN High White/Orange
HS CAN Low Pink/Orange
Keysense Black/Pink
Hood Trigger Tan/Lt. Green
Driver Door Trigger Yellow/Black
Lock Pink/Yellow
Unlock Pink/Lt. Green
Factory Disarm Pink/White
Trunk Release Violet/Yellow
Passenger Door Triggers Gray/Red
Driver Rear Door Trigger Lt. Green/Yellow
Passenger Rear Door Trigger Pink/Lt. Blue
Ford Taurus X 2008-2009
Brake Violet/White
RX Violet/Gray
TX Yellow/Orange
Power Lift gate GrayYellow
12V Red
Ignition White/Ornage
Starter Blue/White
Accessory Violet/Lt. Green
Keysense Blue/Gray
Parking Lights Violet/White
HS CAN High White/Blue
HS CAN Low White
Hood Trigger Blue/Orange
Driver Door Trigger Green/Violet
Lock Blue/Green
Unlock Yellow/Violet
Factory Disarm Green/Violet
Passenger Door Triggers White
Driver Rear Door Trigger Green
Passenger Rear Door Trigger Yellow
44
Pin Polarity Location
2 (+) Brake pedal switch.
3 Data (PATS) connector Type 3.
4 Data (PATS) connector Type 3.
12 (+) Headlight switch or fuse box.
B3 (+) Ignition switch.
I1 (+) Ignition switch.
STA (+) Ignition switch.
A4 (+) Ignition switch.
A2 (+) Ignition switch.
6 Data OBDII.
14 Data OBDII.
17 (-) GEM (Generic Electronic Module) left of steering column.
17 (-) GEM left of steering column.
5 N. Closed GEM left of steering column.
18 (-) GEM left of steering column.
6 (-) GEM left of steering column.
4 (-) GEM left of steering column.
3 (-) GEM left of steering column.
19 N. Closed GEM left of steering column.
Required ONLY when enabling the security features during
20 N. Closed
module flashing.
7 N. Closed
See Tech Tip 1921 at www.directechs.com.
2 (+) Brake pedal switch.
4 Data (PATS) connector Type 3.
3 Data (PATS) connector Type 3.
3 (-) Power lift gate switch.
4 (+) Ignition switch.
1 (+) Ignition switch.
7 (+) Ignition switch.
6 (+) Ignition switch.
5 (+) Ignition switch.
6 (+) SBJ (Smart Junction Box)/dash fusebox.
6 Data OBDII.
14 Data OBDII.
10 N. Closed SBJ (Smart Junction Box)/dash fusebox.
5 N. Closed SBJ/dash fusebox.
17 (-) SBJ/dash fusebox.
4 (-) SBJ/dash fusebox.
8 (-) SBJ/dash fusebox.
2 N. Closed SBJ/dash fusebox.
Required ONLY when enabling the security features during
3 N. Closed
module flashing.
12 N. Closed
See Tech Tip 1921 at www.directechs.com.
Connector Information
Color
Black
Green
Green
Gray
Gray or Black
Gray or Black
Gray or Black
Gray or Black
Gray or Black
Black
Black
Black
White
White
White
White
White
White
White
White
White
Gray
Black
Black
N/A
Black
Black
Black
Black
Black
Black
Black
Black
Black
Gray
Gray
Gray
Gray
Gray
Gray
Gray
© 2018-01-12 Directed. All rights reserved.
Pins Ref.
2 K
4 A
4 A
12 H
13 B
13 B
13 B
13 B
13 B
16 C
16 C
20 D
26 D
26 D
26 D
26 D
26 D
26 D
26 D
26 D
26 D
2 K
4 A
4 A
6 R
7 B
7 B
7 B
7 B
7 B
13 D
16 C
16 C
26 D
26 D
26 D
26 D
26 D
26 D
26 D
26 D
DS4+ FORD1
