Directed Directechs DS4+ Installation Manual page 12

Wire Information
Function Color
Ford E-Series 2008
Brake Dk. Green to Lt.
Green
RX Gray/Orange
TX White/Lt. Green
Keysense Black/Pink
12V Lt. Green/Violet
Ignition Pink/Lt. Green
Starter White/Pink
Accessory 1 Gray/Yellow
Accessory 2 Black/Lt. Green
HS CAN High White/Lt. Green
HS CAN Low Pink/Lt. Green
Driver Door Trigger Red/Pink
Passenger Door Triggers Black/White
Sliding Door White
Parking Lights Brown
Lock (with keyless entry) Orange/Black or Red
Unlock (with keyless entry) Yellow/Red
or Brown
Lock (w/o keyless entry) Pink/Yellow
Unlock (w/o keyless entry) Pink/Lt. Green
Ford E-Series 2009-2014
RX Violet/Gray
TX Yellow/Orange
Keysense Blue/Gray
12V Blue/Red
Ignition White/Orange
Starter Blue/White
Accessory 1 Brown/Yellow
Accessory 2 Violet/Green
Parking Lights Violet/White
HS CAN High White/Blue
HS CAN Low White
Driver Door Trigger Green/Violet
Passenger Front Door Trigger White
Passenger Rear Door Trigger Yellow
Rear Door Trigger Green or Lt. Green
Lock Gray/Yellow
Unlock Violet/Gray
Brake Violet/White
12
Pin Polarity Location
2 (+) Brake switch or drivers kick panel harness to rear.
3 Data (PATS) connector Type 3.
4 Data (PATS) connector Type 3.
1 (-) Bottom of steering column.
2 (+) Ignition switch.
1 (+) Ignition switch.
5 (+) Ignition switch.
8 (+) Ignition switch.
3 (+) Ignition switch.
6 Data OBDII.
14 Data OBDII.
N/A (-) Drivers kick panel.
N/A (-) Drivers kick panel.
N/A (-) Passenger kick panel harness to rear.
N/A (+) Drivers kick panel harness to rear.
N/A (-) Drivers kick panel door harness.
N/A (-) Drivers kick panel door harness.
N/A 5-wire Drivers kick panel door harness.
N/A 5-wire Drivers kick panel door harness.
3 Data (PATS) connector Type 3.
4 Data (PATS) connector Type 3.
10 (-) Ignition switch.
2 (+) Ignition switch.
1 (+) Ignition switch.
5 (+) Ignition switch.
8 (+) Ignition switch.
3 (+) Ignition switch.
6 (+) Driver kick panel or SJB (Smart Junction Box) under drivers dash.
6 Data OBDII.
14 Data OBDII.
14 (-) Driver kick panel or SJB under drivers dash.
2 (-) Driver kick panel or SJB under drivers dash.
15 (-) Driver kick panel or SJB under drivers dash.
3 (-) Driver kick panel or SJB under drivers dash.
17 (-) Driver kick panel or SJB under drivers dash.
4 (-) Driver kick panel or SJB under drivers dash.
40 (+) Brake switch or SJB under drivers dash.
Connector Information
Color
Black
Green
Green
Brown
Gray or Black
Gray or Black
Gray or Black
Gray or Black
Gray or Black
Black
Black
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
Green
Green
Gray
Gray or Black
Gray or Black
Gray or Black
Gray or Black
Gray or Black
Gray
Black
Black
Gray
Gray
Gray
Gray
Gray
Gray
Black
© 2018-01-12 Directed. All rights reserved.
Pins Ref.
2 D
4 A
4 A
6 K
13 B
13 B
13 B
13 B
13 B
16 L
16 L
N/A C
N/A C
N/A O
N/A C
N/A C
N/A C
N/A C
N/A C
4 A
4 A
10 B
13 B
13 B
13 B
13 B
13 B
13 H
16 L
16 L
26 H
26 H
26 H
26 H
26 H
26 H
52 H
DS4+ FORD1
