Directed Directechs DS4+ Installation Manual page 24

Wire Information
Function Color
Mercury Grand Marquis 2005 & 2008-2011
RX Gray/Orange
TX White/Lt. Green
Brake Lt. Green/Red
12V Lt. Green/Violet
Ignition Violet/Orange
Starter Dark Green
Accessory 1 Gray/Yellow
Accessory 2 White/Lt. Blue
Keysense Gray/Yellow or
Black/Pink
Parking Lights Brown
HS CAN High White/Lt. Green
HS CAN Low Pink/Lt. Green
Driver Door Trigger Dark Blue
Trunk Release White/Violet or Red
Lock (with keyless entry) Pink/Yellow
Unlock (with keyless entry) Pink/Lt. Green
Lock (w/o keyless entry) Pink/Yellow
Unlock (w/o keyless entry) Pink/Lt. Green
Passenger Door Triggers Black/Orange
Mercury Grand Marquis 2006-2007
RX Gray/Orange
TX White/Lt. Green
Brake Lt. Green/Red
12V Lt. Green/Violet
Ignition Violet/Orange
Starter Dark Green
Accessory 1 Gray/Yellow
Accessory 2 White/Lt. Blue
Accessory 3 White/Violet
Keysense Black/Pink
Parking Lights Brown
HS CAN High White/Lt. Green
HS CAN Low Pink/Lt. Green
Hood Trigger Violet/Orange
Driver Door Trigger Dark Blue
Trunk Release Violet/Yellow
Lock Pink/Yellow
Unlock Pink/Lt. Green
Passenger Door Triggers Black/Orange
24
Pin Polarity Location
4 Data (PATS) connector Type 3.
3 Data (PATS) connector Type 3.
2 (+) Brake pedal switch.
9 (+) Ignition switch.
1 (+) Ignition switch.
10 (+) Ignition switch.
7 (+) Ignition switch.
5 (+) Ignition switch.
3 (+) Ignition switch.
10 (+) LCM (Lighting Control Module) right of steering column.
6 Data OBDII.
14 Data OBDII.
22 (-) DDM (Drivers Door Module) in drivers door.
12 (-) DDM or trunk release switch.
N/A (-) Drivers kick panel door harness.
N/A (-) Drivers kick panel door harness.
N/A 5-wire Drivers kick panel door harness.
N/A 5-wire Drivers kick panel door harness.
7 (-) DDM in drivers door or drivers kick panel.
Required ONLY when enabling the security features during module
flashing.
4 Data (PATS) connector Type 4.
3 Data (PATS) connector Type 4.
2 (+) Brake pedal switch.
9 (+) Ignition switch.
1 (+) Ignition switch.
10 (+) Ignition switch.
7 (+) Ignition switch.
6 (+) Ignition switch.
5 (+) Ignition switch.
10 (+) Ignition switch.
10 (+) Drivers kick or LCM right of steering column.
6 Data OBDII.
14 Data OBDII.
2 (-) LCM right of steering column.
22 (-) DDM (Drivers Door Module) in drivers door.
N/A 5-wire Drivers kick panel harness to rear.
N/A (+) Drivers kick panel door harness.
N/A (+) Drivers kick panel door harness.
N/A (-) Drivers kick panel harness to rear.
Required ONLY when enabling the security features during module
flashing.
Connector Information
Color
Black
Black
Brown
Gray
Gray
Gray
Gray
Gray
Gray
Black
Black
Black
Black
Black
N/A
N/A
N/A
N/A
Gray
Black
Black
Brown
Gray
Gray
Gray
Gray
Gray
Gray
Gray
Black
Black
Black
N/A
Black
N/A
N/A
N/A
N/A
© 2018-01-12 Directed. All rights reserved.
Pins Ref.
4 A
4 A
5 D
10 B
10 B
10 B
10 B
10 B
10 B
13 E
16 L
16 L
26 M
26 M
N/A C
N/A C
N/A C
N/A C
24 M
4 A
4 A
5 D
10 B
10 B
10 B
10 B
10 B
10 B
10 B
13 E
16 L
16 L
16 E
26 M
N/A C
N/A C
N/A C
N/A C
DS4+ FORD1
