Part 18: Led - Alinx Cyclone IV FPGA User Manual

J3 Expansion Header Pin Assignment
Pin Name
1
3
5
7
9
11
13
15
17
19
21
23
25
27
29
31
33
35
37
39

Part 18: LED

There are six red LEDs on the AX515 FPGA development board, one of
which is the power indicator (PWR), four are users LED lights (LED1~LED4).
The schematic of the four user LED sections is shown in Figure 18-1. When the
FPGA pin output is logic 0, the LED will go out. When the output is logic 1, the
LED is illuminated.
47 / 52
Cyclone IV FPGA Development Board AX515 User Manual
FPGA Pin
GND
N17
N20
P22
P17
R22
P16
R20
R18
U22
U20
V22
Y22
W22
M4
M3
M2
M6
GND
VCC3V3
