Installation Sheet
5
Turn the sample on and purge for the desired time to ensure an accurate sample. This time will vary depending upon amount of
sample available and the length of the sample line.
6
Turn the manual valve to the Sample position.
7
Conduct a run using Micro GC Fusion software.
8
When finished with the sample, shut off the gas source.
9
To depressurize the system, slowly turn the manual valve halfway towards the Vent position.
10
Monitor the pressure regulator on the sample line. When the regulator reads 0 psi, the external sample conditioner is depressurized
and it is safe to remove the sample line.
11
Press on the female Quick Connect fitting to release the sample line.
10 / 19
WARNING
Gas pressure on the HIGH PRESSURE PURGE VENT may be up to 5515 kPa (800 psi). Extreme caution
must be taken to avoid personal injury.
074-732-P1A Micro GC Fusion External Sample
Conditioner Installation Sheet
