Type 3
Refer to "Pre-installation and application warnings" on page 4 for important information, such as the description of special notes referenced in the diagram (
(-) Parking Lights: Blue, pin 18
Headlight Switch
(White conn. at
10 9
8
7 6 5 4 3 2 1
headlight switch)
20191817161514131211
Autolights:
Orange, pin 19
Junction Connector
(White conn.
behind glove box)
IMO: Green, pin 10
CUT
(-) Trunk Release: Blue, pin 5
5
Trunk Release Switch
(White conn.
at release switch)
13
(-) Lock: Black, pin 9
10
1
2 11
9
20
19
12
(-) Unlock: Gray, pin 19
If the module programs,
IMI: Tan, pin 11
but the vehicle starts and
stops following a remote
start command, reverse
1
9
the IMI wires. The
3
7
10
11
18
Yellow/Black and
12
16
Lt.Green wires need to be
on the ECM side.
Starter 2: Lt. Blue, pin 15
(+) Accessory: Red, pin 11
(White conn. behind glove box)
17
15
11
10
9
Starter 1:
40
35
34
32
26
Black, pin 17
(+) Ign. 2: Lt. Green, pin 34
(+) Ignition 1: Yellow, pin 35
Junction Connector
(White conn. drivers kick panel)
IMI Data (conn. side): Yellow/Black: 8
CUT
(-) Parking Light Output: Lt. Green/Black: 1
(-) Lock Output: Dark Green/Black: 3
(-) Trunk Release Output: Red/White: 4
(-) Unlock Output: Dark Blue/Black: 9
Hood Pin
Siren
Autolights Interrupt (conn. side): Blue/White: 1
Autolights Interrupt (vehicle side): Blue: 3
(+) Starter 2 Output: White: 5&11
IMI Interrupt (conn. side): Lt.Green: 8
IMI Interrupt (vehicle side): Lt.Green/White: 9
(+) Ignition 2 Output: Pink/White: 4
Starter Input (Key side) : Green: 6
Power ECU
(+) 12V: Black, pin 1
1
18
HS CAN High: Pink, pin 6
1
9
Diagnostic Connector OBDII
(connector side view)
HS CAN Low: White, pin 14
HS CAN Low: Tan: 1
HS CAN High: Tan/Black: 2
IMO Data: Orange/Black: 7
(+) Siren Output: Brown/Red: 11
(-) Hood Input: Gray: 21
DS4+
Proper Fuse
Positioning
(+) 12V Input: Red: 6&12
(-) Ground: Black: 10
(+)12V Input: Red/Black: 2
(+)12V Input: Red: 5
(+) Starter Output : Violet: 7
(+) Accessory Output: Orange: 8
Slide
(+) 12V Input: Red/White: 9
to open
(+) Ignition 1 Output: Pink: 10
It is important to check that the
fuses are positioned correctly.
1
Fuse Box
(White conn. under driver dash)
