Directed DS4+ Installation Manual page 18

Wire Information
Function Color
Lexus IS 350C (Smart Key) 2010-2015
Parking Brake Yellow
12V Black/White
CAN H Green
CAN L White
Parking Lights Blue
Autolights Orange
Ignition 1 Lt. Green
Ignition 2 Pink
Accessory Lt. Green
Starter 1 Lt. Blue
Starter 2 Violet
IMO White
IMI Pink
Lock Blue
Unlock White
Trunk Release Pink
18
Pin Polarity Location
1 (-) Parking Brake Switch.
1 (+) Passenger Dash Fuse Box.
6 Data OBDII.
14 Data OBDII.
18 (-) Headlight Switch.
19 (-) Headlight Switch.
35 (+) Power Source Control ECU behind glove box.
34 (+) Power Source Control ECU behind glove box.
11 (+) Power Source Control ECU behind glove box.
17 (+) Power Source Control ECU behind glove box.
15 (+) Power Source Control ECU behind glove box.
15 Data Driver Kick Panel.
14 Data Driver Kick Panel.
5 (-) Power Window Master Switch in driver door.
4 (-) Power Window Master Switch in driver door.
4 or 6 (-) Trunk Release Switch.
Connector Information
Color
Brown
White
White
White
White
White
White
White
White
White
White
White
White
White
White
Black
