Directed DS4+ Installation Manual page 20

Vehicle wiring reference chart
This section provides vehicle wiring information to guide you through the various stages of your installation. Refer to
www.directechs.com for additional information.
Wire Information
Function Color
Toyota FJ Cruiser (G Key) 2010-2014
12V Blue/Black
Ignition 1 Black/Red
Ignition 2 Blue/Yellow
Accessory White/Green
Starter 1 Green/Black
Starter 2 Black/White
CAN H Pink
CAN L Violet
Parking Lights Green
Autolights Blue
Security Light Violet/White
IMO Blue/Orange
IMI Blue/Yellow
Toyota FJ Cruiser (L Key) 2010-2014
12V Blue/Black
Ignition 1 Black/Red
Ignition 2 Blue/Yellow
Accessory White/Green
Starter 1 Green/Black
Starter 2 Black/White
CAN H Pink
CAN L Violet
Parking Lights Green
Autolights Blue
Security Light Violet/White
IMO Blue/Orange
IMI Blue/Yellow
20
Pin Polarity Location
7 (+) Ignition Switch.
6 (+) Ignition Switch.
4 (+) Ignition Switch.
3 (+) Ignition Switch.
8 (+) Ignition Switch.
1 (+) Ignition Switch.
6 Data OBDII.
14 Data OBDII.
14 (-) Headlight Switch.
12 (-) Headlight Switch.
15 (+) A/C Amplifier behind radio.
20 Data ECM behind glove box, second connector from bottom.
14 Data ECM behind glove box, second connector from bottom.
7 (+) Ignition Switch.
6 (+) Ignition Switch.
4 (+) Ignition Switch.
3 (+) Ignition Switch.
8 (+) Ignition Switch.
1 (+) Ignition Switch.
6 Data OBDII.
14 Data OBDII.
14 (-) Headlight Switch.
12 (-) Headlight Switch.
15 (+) A/C Amplifier behind radio.
20 Data ECM behind glove box, second connector from bottom.
14 Data ECM behind glove box, second connector from bottom.
Connector Information
Color
White
White
White
White
White
White
White
White
Black
Black
White
White
White
White
White
White
White
White
White
White
White
Black
Black
White
White
White
© 2017-09-25 Directed. All rights reserved.
Pins Ref.
8 A
8 A
8 A
8 A
8 A
8 A
16 B
16 B
17 C
17 C
20 D
36 E
36 E
8 A
8 A
8 A
8 A
8 A
8 A
16 B
16 B
17 C
17 C
20 D
36 E
36 E
DS4+ TL4
