Type 4 - Directed DS4+ Installation Manual

Type 4

Refer to "Pre-installation and application warnings" on page 4 for important information, such as the description of special note referenced in the diagram (
Orange, pin 19
Driver Door Window Switch
(White conn. in driver door)
Lock:
Blue, pin 4
10 4 1
20 13 11
Unlock:
White, pin 13
Only for manual
transmissions
1
Parking Brake Switch
(Brown conn. at parking brake)
15
Headlight Switch
(White conn. at headlight switch)
10 9 8 7 6 5 4 3 2 1
20191817161514131211
Autolights:
(+) Parking Lights: Blue, pin 18
(-) Trunk Release: Pink, pin 6
CUT
6
Trunk Release Switch
(White conn. at release switch)
(+) Starter 2: Violet, pin 15
(+) Starter 1:
Lt. Blue,
(+) Accessory: Lt. Green, pin 11
pin 17
(White conn. behind glove box)
17 15 11 10
40 35 34 32
(+) Ignition 1:
Lt. Green, pin 35
IMO: Junction conn.
White, pin 15
(Top white conn. driver kick panel)
15 14 12 7
22 13 6
28 23
38 29
44
60 51 50 45
IMI: Pink, pin 14
CUT
Siren
Hood Pin
Autolights Interrupt (conn. side): Blue/White: 1
IMI Interrupt (vehicle side): Lt.Green/White: 9
Power ECU
1
9
26 18
(+) Ignition 2:
Pink, pin 34
If the module programs, but the vehicle starts and stops
following a remote start command, reverse the IMI wires. The
Yellow/Black and Lt.Green wires need to be on the ECM side.
1
39
HS CAN High: Green, pin 6
1
9
HS CAN Low: White, pin 14
HS CAN Low: Tan: 1
HS CAN High: Tan/Black: 2
IMO Data: Orange/Black: 7
IMI Data (conn. side) Yellow/Black: 8
(-) Parking Light Output: Lt.Green/Black: 1
(-) Lock Output: Dark Green/Black: 3
(-) Trunk Release Output: Red/White: 4
(-) Unlock Output: Dark Blue/Black: 9
(+) Siren Output: Brown/Red: 11
(-) E-Brake Input: White/Black: 17
(-) Hood Input: Gray: 21
Proper Fuse
Autolights Interrupt (vehicle side): Blue: 3
Positioning
(+) Starter 2 Output: White: 5&11
(+) 12V Input: Red: 6&12
IMI Interrupt (conn. side): Lt.Green: 8
(-) Ground: Black: 10
(+) 12V Input: Red/Black: 2
(+) Ignition 2 Output: Pink/White: 4
(+) 12V Input: Red: 5
Starter Input (Key side) : Green: 6
(+) Starter Output : Violet: 7
(+) Accessory Output: Orange: 8
(+) 12V Input: Red/White: 9
(+) Ignition 1 Output: Pink: 10
12V:
Black/White,
It is important to check that the
pin 1
fuses are positioned correctly.
1
Passenger Fuse Box
(White 1-pin conn.)
).
Diagnostic
Connector OBDII
8
(connector side view)
16
DS4+ DS4
DS4
Slide
DS4+
to open
DS4+ TL4
© 2017-09-25 Directed. All rights reserved.
