Install the Access Point
4. Insert the 0.5 in. (12.7 mm) wide stainless-steel cable clamps through the long slots on the sides of
pole bracket.
Figure 14: Long slots on the pole part of the KT-147407-02 bracket
Callout
1
5. Position and insert the ends of the cable clamps around the pole.
6. Tighten the clamp screws to a torque of 11 in-lbs.

Attach the Access Point to a Pole Using the KT-147407-02 Pole Part

Before You Begin
If 1-axis tilt is not required, you can use the pole part of the KT-147407-02 bracket for pole installation.
The following hardware is required:
•
KT-147407-02 pole part
•
Two 0.5 in. (12.7 mm) wide stainless-steel cable clamps
•
Access point
•
Four M6 hex-head screws
Procedure
1. Attach the KT-147407-02 pole part to the access point using four M6 hex-head screws.
Use the semi-circular cuts on the pole part of the KT-147407-02 bracket to attach the screws.
Description
Long slots on the sides of the pole part of the KT-1474017-02 bracket. These
slots are used to insert the 0.5 in. (12.7 mm) wide stainless-steel cable clamps.
Attach the Access Point to a Pole Using the
ExtremeWireless™ AP460i/e Access Points
KT-147407-02 Pole Part
31
