Install the Access Point on a Hard Vehicle Surface Using
the WS-MBV-VMM Vehicle Bracket (#32216)
3. Align the MBO-ART02 articulating mounting bracket holes against the wall attachment holes and
attach the bracket using four M4 hex-head screws.
Install the Access Point on a Hard Vehicle Surface Using the WS-MBV-VMM Vehicle
Bracket (#32216)
About This Task
The WS-MBV-VMM vehicle bracket (#32216) is used to mount the access point on a wood or a metal
vehicle surface. The vehicle bracket has four parts:
•
Flat plate with thumbscrews, called the access point attach assembly plate
•
Stiffener plate 1. It is used with the access point attach assembly plate
•
Stiffener plate 2. It is used with the access point attach assembly plate
•
Vehicle attach assembly plate with PEM® fasteners
Table 9: WS-MBV-VMM vehicle bracket (#32216) box contents
Item
VMM vehicle attach assembly
VMM access point attach assembly
Phillips pan-head M4 (15 mm) screws
The installer must provide the following hardware:
Access point
Screws or bolts to attach the vehicle attach
assembly plate
Torque wrench or a screwdriver
24 ExtremeWireless™ AP460i/e Access Points
Description
Vehicle attach plate with PEM® fasteners
Access point attach flat plate with stiffener 1 and
stiffener 2
Four screws to attach the access point attach
assembly plate to the access point
The access point that you are using for installation
Four screws or bolts
Required to attach the screws or bolts, and
assembly plates
Install the Access Point
