Daikin VRV IV+ Service Manual page 469

st
Mode 1 code
13(23) 0
1
2
3
4
5
6
7
REYQ8~20+REMQ5U7Y1B
VRV IV+ Heat Recovery
ESIE18-15B – 2020.05
Description function
Air flow amount setting (ceiling
height)
Number of air outlet 4-blow
panel
Swing pattern setting if 4 swing
motors
Output to flap motor
Air flow position setting
ESP setting phase control motor
External static pressure manual
set
Thermostat swing
nd
2 code Description selection
01 Standard
02 High
03 Extra high
01 4-blow directions
02 3-blow directions
03 2-blow directions
01 All direction simultaneously swing
02 --
03 Opposite sides synchronization
swing
01 Enabled
02 Disabled
03 --
01 Draft prevention
02 Standard
03 Ceiling soiling prevention
01 Standard
02 Increase step 1
03 Increase step 2
04 --
01 --
02 50 Pa
03 60 Pa
04 70 Pa
05 80 Pa
06 90 Pa
07 100 Pa
08 110 Pa
09 120 Pa
10 130 Pa
11 140 Pa
12 150 Pa
13 160 Pa
14 180 Pa
15 200 Pa
01 Equipped
02 Not equipped
6 Technical data
|
Service manual
469
