6.9.5 Mode 2: Field settings
In mode 2 you can make field settings to configure the system. The LEDs give a binary representation of the
setting/value number.
(
)
*
This column shows the number of times you have to push the SET button (BS2) to access the field setting.
(
)
**
The bold content is the default setting.
(
)
N°
*
0
Cool/heat selection
1
Cool/heat unified address
2
Low noise/demand address
5
Indoor unit forced fan H
6
Indoor unit forced thermo ON
8
Te setting
9
Tc setting
10
Defrost selection setting
12
Low noise/demand operation by
external input
13
AirNet address
REYQ8~20+REMQ5U7Y1B
VRV IV+ Heat Recovery
ESIE18-15B – 2020.05
Item
Display
2.00
0
Individual
1
Master (DTA104A6* option required)
2
Slave (DTA104A6* option required)
2.01
0
Possible 0-31
2.02
0
Possible 0-31
2.05
0
Disabled
1
Enabled
2.06
0
Disabled
1
Enabled
2.08
0
Auto
1
3 ˚C
2
6 ˚C
3
7 ˚C
4
8 ˚C
5
9 ˚C
6
10 ˚C
7
11 ˚C
2.09
0
Auto
1
41 ˚C
2
42 ˚C
3
43 ˚C
4
44 ˚C
5
45 ˚C
6
46 ˚C
7
48 ˚C
2.10
0
Short
1
Normal
2
Long
2.12
0
Disabled
1
Enabled
2.13
0
Possible 0-63 (0 is not a valid airnet
address)
6
Technical data
|
(
)
Content
**
Service manual
461
