REYQ8~20+REMQ5U7Y1B
VRV IV+ Heat Recovery
ESIE18-15B – 2020.05
Charge port / Service port
Stop valve
Filter
Check valve
Pressure relief valve
Thermistor
Solenoid valve
Heat sink (PCB)
Capillary tube
Expansion valve
4‑way valve
Propeller fan
High pressure switch
Low pressure sensor
High pressure sensor
Oil separator
Accumulator
Heat exchanger
Compressor
Double tube heat exchanger
Distributor
Liquid receiver
6
Technical data
|
Service manual
403
