REYQ8~20+REMQ5U7Y1B
VRV IV+ Heat Recovery
ESIE18-15B – 2020.05
a
a
a Screw
b Switch box cover
c Branch selector box PCB
To remove the top plate
4 Loosen and remove the top plate screws.
5 Lift the top plate and remove it from the unit.
a
a
b
a Screw
b Cover
b
a
a
c
b
a
a
3
Components
|
Service manual
327
