2. second button is supposed to dial 123#1*2Flash3 during day and night, then the
programming is 102123#1 ** 2 *# 3 and wait for ♫, then 202123#1 ** 2 *# 3 and wait
for ♫
Note. If you are not using mode Day/night or mode 2 groups of numbers, then it is
recommended to set mode Day/Night (parameter 47) and then set the same code for
switching over Day/Night (parameters 45 and 46). His way it is guaranteed that A-
VarioBell will always be in Day mode and you can only programme telephone
numbers for the day mode (parameter 1).

5.2 Relays

Parameter Value
31
– relay number [1-2]
r
m – relay mode [1-8 for r=1 is not regime m=5]
modes m=1, 4, 5, 6 are explained in detail in Relay modes Tab. 1 on page 31
mode relay – switched on with command (internal code) or with a
m=1
password (external) 1 impulse for length of time t1/t4 (use for electric
locks) or 2 impulses when it switches on for time t1/t4, off for t2/t5 and
again switches on for t1/t4 (opening of sliding gates).
m=2 is switched on for time when the line is picked up (camera) – switches on
when system picks up and off when it disconnects
m=3 is switched on for time when the line is picked up and extra time t1/t4
after disconnection (lights) - switches on for time when the line is picked
up and extra time t1/t4 after disconnection (for this time the line is busy,
after switching DIP 3, 4 and setting of parameter 64 line after t1/t4
disconnected)
m=4 mode button – switched on when any button is pressed and off after
t1/t4 (use is for example connection of external bell or siren)
m=5 mode gradual opening – into this mode it is possible to set only relay 2,
because relay 1 will then automatically be set to m=1. With command
(internal code) or password (external code) relay 1 is activated for length
of time1, then time t3 is running before relay 2 is switched, then relay 2 is
activated for time t4 and after the system disconnects. If given command
or password answers to 2 impulses then in the sequence there will be
always 2 impulses separated by time t2/t5. Explanation is in Tab.1.
Note. Command or password for relay 1 starts the whole sequence, if you use
command or password for relay 2 then only relay 2 is controlled in the same way
as in mode m=1.
m=6 switches on depending on pressed button (it is set in parameter 31r*). In
this way it is possible to choose only one button for each relay, which
when pressed switches on relay for time t1/t4. This mode is used instead
of connecting separate doorbell to the system.
A-VarioBell – User and service manual
40
Meaning
r m relay r operates in regime m
Basic
(1-8) 11 21
