m=7 permanent switch on / off – possible to use when switch DIP
3,4+param.64. With command for 1 impulse it is switched on, for impulse
2 is off. The system remembers its state even after the line is
disconnected. This regime is used for watering, green house opening,
switching on heating etc.
m=8 switching depends on setting Day/Night mode – for switching (DIP 3,
4+param64). Appropriate relay switching either according status
DAY/NIGHT mode ( by DTMF code) or when is activated automatic
switching DAY/NIGHT mode it is possible activate relay according setting
of switching times (automatically) from week table (when is ON - rameter
084) . Then is possible use it for example for Heating activation etc...
Parameter Value
31
– relay number [1-2]
r
tt – button number (memory), always in two digits [01-99]
This parameter is only for relay mode m=6. Value tt determines which button
starts switching on for time t1/t4 of relay r.
Parameter Value
32
33
34
– relay number [1-2]
r
– order [1 - 5] for 1 impulse. 5 passwords (external codes) from A-
p
VarioBell's buttons (external code of code lock)
– order = * to set password (external code) for 2 impulses
p
hh... – password (external code) for relay switching on from button or
keyboard [2 to 6 places]. Buttons 1 - 10 are programmed as numbers
1-0.
All together 3x12 passwords, depending on the Day/Night setting,
combinations are be input either with the help of the buttons (first 10) or from
the connected keyboard (after pressing the key sign). Switching on a relay is
affected by the relay regime and the choice Day/Night, if the mode 2 groups
of numbers is set, the system is constantly in mode DAY.
Meaning
button tt switches on relay r in mode m=6
r* tt
Meaning
In mode Day + Night password hh... for
rp
relay r, in order p=1-5 for 1 impulse and
hh...
p=* for 2 impulses
In mode Day password hh... for relay r, in
rp
order p=1-5 for 1 impulse and p=* for 2
hh...
impulses
In mode Night password hh... for relay r,
rp
in order p=1-5 for 1 impulse and p=* for 2
hh...
impulses
(00-999999)
(00-999999)
(00-999999)
A-VarioBell – User and service manual
default
01
(01-99)
Default
-
-
-
41
