Mounting process:
A. Preparation of mounting holes in the wall – recommended height is about
160cm from ground. Dimension of holes depends on number of modules
and here we mention dimensions for 1,2 and 3 modules (basic mounting
boxes). The bigger sets are completed from those boxes by their
combination ( under or next each other).
Modules
height mm
width mm
depth mm
B. Peparation of mounting box for cable and mutual connection of mounting
boxes
C. Mounting box fixing into hole in the wall
D. Inserting of each modules into into fixing frame
E. Inserting of spring to bottom part of mounting box
F. Inserting of fixing frame into spring in mounting box
G. Installing of fixing frame to mounting box by 4 screws (supplied)
H. Completing of design frame – firstly screw up side rails with bottom part
I. Into design frame insert front panels of each modules
J. Last module (module on top) is slide into design frame
K. At the end screw up top part of design frame into side rails
L. This complete as set is on picture (H+I+J+K) for further set into next
mounting box
M. Last step is put covers on design frame
A-VarioBell – User and service manual
24
1
140
125
56
2
257
125
56
3
374
125
56
