Switching a relay on with 2-impulses is used for sliding gates replacing a gate
entry.
Example:
Command for switching on 2 relays 1 impulse is for example *8, the command for
disconnection is *8 and the command for switching on 2 relays 2 impulses is *9.
Programming: 352*8 ♫ , 432*8 ♫ , 362*9 ♫.
If you are in conversation with the A-VarioBell, the command to open a gate would be
button 9, the first impulse starts and the gate opens, the second impulse stops it, the
time the gate is opened "opened space" is set by time between the impulses (parameter
30) after people enter press 8, then A-VarioBell makes 1 impulse and disconnects, gate
closes.
Parameter Value
37
– relay number [1-2]
r
ss – time t1 / t4 for which relay 1 / 2 is switched on [2 spaces 00-99], where
time 00 means 0,5sec
Parameter Value
38
– relay number [1-2]
r
p – parameter whether it is allowed p=1 or disallowed p=0 to control relay
during incoming call.
To prohibit 'control' during an incoming call, for use with relay 2 in mode 1 for
controlling a garage door, so the electronics open the garage door and the car
passing through the door, closes the door. Then control from the phone could
result in a permanently opened door (i.e. the door doesn't close because car
didn't enter).
Parameter Value
39
xx – time t3 between switching on relays 1 and 2 when regime m=5 is set
(gradual opening) [2 spaces 00-99] ], where time 00 means 0,5sec
Parameter Value
30
– relay number [1-2]
r
Meaning
time ss [sec] of relay r on for time t1/t4
r ss
Meaning
relay r control during incoming call
r p
Meaning
time xx [sec] between switching on relays
xx
1 and 2 in regime m=5 - time t3
Meaning
time zz [sec] between impulses for
r zz
switching on relay r 2 impulses- time t2/t5
A-VarioBell – User and service manual
default
105 205
(01-99)
default
11 21
(0/1)
default
10
(01-99)
default
105 205
(01-99)
