– time t2 / t5 between first and second impulse for switching on relay 1 / 2
zz
[2 spaces 00-99], where time 00 means 0,5sec
Parameter Value
3*
– relay number [1-2]
r
– exit button mode: e=0 - off, e=1 – on for 1 impulse, e=2 – on for 2
e
impulses
Rameter Value
3#0
– turns on transmission serial code to activate the first switch.
p
CAUTION - at activation this function never connect to the circuit electric lock
without board COSW - code relay - threatens to destroy the relay in A-VarioBell
door phone!
The following codes may be the same or different for the resolution switching
on multiple parallel connected relay code.
Rameter Value
3#1 abcd
abcd –
A-VarioBell sends a serial code for the code relay (COSW) after
evaluation code from keys (keypad) namely for 1 pulse
Rameter Value
3#2 abcd
abcd –
A-VarioBell sends a serial code for the code relay (COSW) after
evaluation code from telephone (DTMF) namely for 1 pulse
Rameter Value
3#3 abcd
abcd –
A-VarioBell sends a serial code for the code relay (COSW) after
evaluation code from keys (keyboard) namely for 2 pulses
A-VarioBell – User and service manual
44
Meaning
Exit button for relay r
r e
Description
p = 1 enabled / disabled p = 0 connection
p
code relay COSW
Description
activation code 1 pulse from buttons
Description
activation code 1 pulse from phone
Description
activation code 2 pulses from buttons
default
10 20
(0/1/2)
Default
(0/1)
Default
(0000-1111)
Default
(0000-1111)
Default
(0000-1111)
0
0000
0000
0000
