Installing the Suspension System

B. For systems up to 350' [107 m]
2.Locate the Power Lift Winch. The Power Lift Winch requires a support that will span, in a wood frame house
at least 3 rafters, and in a steel frame house at least 2 rafters.
3.Locate the Power Unit and Feed Hopper. Special support is required at each Power Unit and Feed Hopper
location.
4.Determine the Drop Location and length. Suspension systems are based on ceiling heights of 14' [4.3 m]
with suspension drop points every 8' [2.4 m]. DO NOT EXCEED 10' [3 m] BETWEEN SUSPENSION
DROPS.
5.Determine the location for Screw Hooks. Mark a straight line or use cable to locate Screw Hooks. Use the
offset of Screw Hooks where necessary.
Installing the Suspension System

Power Lift Winch Installation

1.Bolt the Power Winch, fully assembled, to the
Power Lift Winch Support, either a 2'' x 8''
[50x200 mm] board that will span at least 3 raf-
ters or a 3/8'' [9.5 mm] thick steel plate welded to
two pieces angle iron that are each long enough to
span at least 2 rafters, using
5/16-18 hardware supplied in the Hardware Pack-
age. The brake mechanism will extend toward
one side.
Install a Cable Hook, supplied in
Hardware Package, between the
mounting bolt and Power Winch
frame, as shown in Figure 6.
Assembling the Power Winch to the
Rafters
2.Attach the Power Lift Winch Support
(with the Power Winch secured) to the
ceiling at the center of the feeder line.
See Figure 7. The Power Lift Winch
Support must be parallel to the feeder
line and must span at least 3 rafters in
a wood frame house and 2 rafters in a
steel frame house.
note: If the hopper is located at the center of the feeder line, locate the Power Winch a few feet offset from the
center of the feeder line. However, the Winch Drum must be directly in line with where the main cable is to be
installed.
