Chore-Time C2 PLUS Installation And Operator's Manual page 57

MODEL C2® PLUS & MODEL G™ PLUS with Proximity Sensor Feeding System
Item
1 Danger/Product Identification Decal
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21*
22
23
24
25
26
27
*Actuator Switch, Chore-Time part number 7114, is no longer available. When replacing, use 7114 Switch
Replacement Kit Part Number 46678.
MF2495A
Description
Danger Decal
Back Cover
Front Panel
Tube Support
Paddle Retainer
Pivot Bracket
Spring
#10-32 Lock Nut
Gasket
Switch Box Cover
Gasket
Actuator Pin
Support Cone Assembly
Tube Retainer
Cord Assembly
1/2" Liquid Tight Connector
Machined Switch Box
Switch Bracket
Switch Insulation
Actuator Switch
Cut Sleeve
Mylar Assembly
Switch Paddle
Feeder Pan
Feeder Grill
Adjustment Cone
MODEL MODEL MODEL
C2 PLUS C2 PLUS G PLUS
Standard Shallow Standard
Part No. Part No. Part No.
40945 42013 40946
2529-658 2529-248 2529-657
2527-9 2527-9 2527-9
25047 25047 25047
25046 25046 25046
41364 41364 41364
25045 25045 25045
25048 25048 25048
6972 6972 6972
6963 6963 6963
6968-1 6968-1 6968-1
6776 6776 6776
6777 6777 6777
8757 8757 8757
40947 37371 40947
14756 14756 14756
4999-49 4999-49 4999-49
24685 24685 24685
34842 34842 34842
46122 46122 46122
1907-5 1907-5 1907-5
46091 46091 46091
43110 43110 43110
25318 25318 25318
46123 46123 46123
41501 41500 41501
39567 39567 38599
38604 41504 38604
Parts List
MODEL
G PLUS
Shallow
Part No.
42029
2529-694
2527-9
25047
25046
41364
25045
25048
6972
6963
6968-1
6776
6777
8757
37371
14756
4999-49
24685
34842
46122
1907-5
46091
43110
25318
46123
41500
38599
41504
