MODEL C2® PLUS & MODEL G™ PLUS with Proximity Sensor Feeding System
Mechanical Switch Adjustment
procedure for Control Units
Refer to See Figure 57.
A. Turn the adjustment nut counter-
clockwise until the switch clicks.
B. Turn the adjustment nut clockwise until
the switch clicks.
C. Turn the adjustment nut counter-
clockwise 3/4 turn.
Sensitivity Timer: The Feeder Comes with
the Sensitivity Timer adjustment Screw factory set and Glued in position. (Do not Adjust).
Time Delay: The Delay Time is Factory Set to 3 Minutes. See Figure 58.
To adjust the Time Delay:
•For less time — turn Time Delay Selector counter-clockwise.
•For more time — turn Time Delay Selector clockwise.
End Control
Mid-line Control
MF2495A
1)Adjustment Nut
3
Item
1
2
3
Figure 58.Proximity Sensor Adjustment
Figure 57.Switch Adjustment
The Delay Adjustment Screw is set
1
to the "7 o'clock" position at the fac-
tory. At the "7 o'clock" position the
Delay time is 3 minutes.
1
7
5
6
The Sensitivity Adjustment
2
Screw is set at the factory and
glued in place.
Description
Delay Time Adjustment Screw
Sensitivity Adjustment Screw
Proximity Sensor
Maintenance
1660-23 1/2001
2
3
4
37
