Mechanical Switch Three Phase(Ø) Wiring Diagram: 220 V; Mechanical Switch Three Phase(Ø) Wiring Diagram: 380/415 V - Chore-Time C2 PLUS Installation And Operator's Manual

MODEL C2® PLUS & MODEL G™ PLUS with Proximity Sensor Feeding System
Mechanical Switch Three Phase(Ø) Wiring Diagram: 220 V.
FROM DISCONNECT OR
CONTROL DISCONNECT
220 VOLTS 50 HZ
THREE PHASE
PHASE
PHASE
PHASE
SET OF FUSES
SHORT CIRCUIT
PROTECTION
(NOT SUPPLIED)
CONTACTOR
C1
CURRENT SENSOR
(AVAILABLE)
K1
Mechanical Switch Three Phase(Ø) Wiring Diagram: 380/415 V.
FROM DISCONNECT OR
CONTROL DISCONNECT
380/415 VOLTS 50 HZ
THREE PHASE
PHASE
PHASE
PHASE
NEUTRAL
SET OF FUSES
SHORT CIRCUIT
PROTECTION
(NOT SUPPLIED)
CONTACTOR
C1
CURRENT SENSOR
(AVAILABLE)
K1
MF2495A
L1 L2 L3
T1 T2 T3
FEEDER LINE MOTOR
M1
220/230 VOLTS 50 HZ
3 PH
THREE PHASE
L1 L2 L3
T1 T2 T3
FEEDER LINE MOTOR
M1
380/415 VOLTS 50 HZ
3 PH
THREE PHASE
TO ADDITIONAL
FEEDER LINES
MID LINE
CONTROL BYPASS SWITCH
CONTROL UNIT
END CONTROL
95
K1
96
C1
1255-109 10/2000
TO ADDITIONAL
FEEDER LINES
MID LINE
CONTROL BYPASS SWITCH
CONTROL UNIT
END CONTROL
95
K1
96
C1
Wiring
(NOT SUPPLIED)
(NOT SUPPLIED)
1255-110 10/2000
33
