Chore-Time C2 PLUS Installation And Operator's Manual page 20

Installing the End Control, Boot Assembly, and Auger
Figure 32. Use the Driver Block to secure the auger to the Output Shaft.
1) Driver Block
7.Attach the Anchor Plate and Gearhead Assembly to the Control Unit Body using the included 1/4'' Lock
Washers and 1/4-20 x 1/2'' Bolts. See Figure 33.
8.Install the Metal Water Tight Connector (Item 1) in the Feed Line Motor (Item 2). Cut the Flex Conduit
(Item 3) to length. Slide the wires from the end control through the Flex Conduit (Item 3). Install the Flex
20
3) Control Unit not
shown for clarity
2) Drive Tube Weldment
Figure 32.Auger Driver Components
Figure 33. Attaching the Anchor Plate and Gearhead Assembly
to the Control Unit Body
MODEL C2® PLUS & MODEL G™ PLUS with Proximity Sensor Feeding System
4) 1/4-20 x 1-1/2"
Socket Head Bolt
1255-93 4/2001
6) Auger
MF2495A
