Levelflex M FMP43 with FOUNDATION Fieldbus
Endress+Hauser
30 O-ring Material; Temperature:
5 EPDM, FDA, USP Cl. VI; - 20 °C to 130 °C
6 Kalrez, FDA, USP Cl. VI; - 20 °C to 150 °C
9 Special version, to be specified
40 Process Connection:
-- Threaded boss --
U1J Thread M24, 316L, install > accessory weld-in adapter
-- Clamp connections --
TCJ Tri-clamp ISO2852 DN25-38 (1 to 1-1/2"), 316L
TDJ Tri-clamp ISO2852 DN40-51 (2"), 316L
TFJ Tri-clamp ISO2852 DN70-76.1 (3"), 316L
-- Hygienic connections --
T7J SMS 1-1/2" PN25, 316L
TXJ SMS 2" PN25, 316L
MAJ DIN 11864-1 A DN 25 Pipe DIN 11850, 316L
MQJ DIN 11851 DN 40 PN 40, 316L
MRJ DIN 11851 DN 50 PN 40, 316L
S1J NEUMO BioControl DN25 PN16, 316L
-- ANSI flanges --
AEJ 1-1/2" 150 lbs RF, 316L flange ANSI B16.5
AFJ 2" 150 lbs RF, 316L flange ANSI B16.5
YY9 Special version, to be specified
50 Power Supply; Output:
B
D 2-wire; PROFIBUS PA
F
G 4-wire 90 - 250 VAC; 4 - 20 mA SIL HART
H 4-wire 10.5 - 32 VDC; 4 - 20 mA SIL HART
Y
60
70
80
90
2-wire ; 4 - 20 mA SIL HART
2-wire; FOUNDATION Fieldbus
Special version, to be specified
Operation:
1 W/o display, via communication
2 4-line display VU331,
3 Prepared for FHX40,
9 Special version, to be specified
Type of Probe:
1 Compact, basic version
5 Compact, detachable
6 Remote, cable 3 m, detachable
7 Remote, cable 6 m, detachable
9 Special version, to be specified
Housing:
A F12 Alu, coated IP68 NEMA 6P
C T12 Alu, coated IP68 NEMA 6P, separate terminal compartment
B F23 316L IP68 NEMA 6P
D T12 Alu, coated IP68 NEMA 6P + OVP,
D Separate terminal compartment, OVP = overvoltage protection
Y Special version, to be specified
Cable Entry:
2 Cable gland M20 (EEx d > thread M20)
3 Thread G 1/2
4 Thread NPT 1/2
5 Plug M12
6 Plug 7/8"
9 Special version, to be specified
Identification
