A. Connect Adeept Ultrasonic Module to Cable
Assemble the following components
Female-Female
Cable x2
Male-Female Cable x2
Effect diagram after assembling
Female-Female Cable connects to VCC
and GND respectively
B. Connect Adeept Passive Buzzer Module to Cable
Assemble the following components
Adeept Passive Buzzer Module x1
Effect diagram after assembling
Adeept Ultrasonic Module x1
Male-Female Cable x1
Female-Female Cable x2
Female-Female Cable connects to
"+"and "-"respectively
