M. Switch on the power and install the rocker arm on the steering gear.
Before switching on the power, we need to check whether Adeept 32 Channel PWM Drive is
flush with Adeept UNO R3
The correct result
Adeept 32 Channel PWM Drive
Adeept UNO R3
The wrong result
As the installation and wiring produce pressure on
Adeept 32 Channel PWM Drive, when the pressure
is on one side, it can make Adeept 32 Channel
PWM Drive tilt, resulting in the contact of the 32
Channel PWM Drive and Adeept UNO R3, as a
result, it causes short circuit, so every time before
we plug in power, you need to ensure that Adeept
32 Channel PWM Drive is not tilted (circuit safe) to
be powered on.
