Remote Control
A. Fix the 18650x2 Battery Holder-A and Adeept Remote Control Shield.
Assemble the following components
M3*10 Countersunk
Head Screw
18650x2 Battery
Holder-A
x1
Adeept Remote
Control Shield
x1
Effect diagram after assembling
54
x2
M3 Nut x2
The wiring on the 18650x2
Battery Holder shall not be
pressed between the
18650x2 Battery Holder
and the Adeept Remote
Control Shield, so as to
avoid short circuit caused
by metal puncturing on the
Adeept Remote Control
Shield.
