4. Assembly

4.1. Pedestal Assembly.

1. Connect the Adeept Touch Button to 3-Pin Wire.
Assemble the following components
Adeept Touch Button x1
Effect diagram after assembling

2. Connect the OLED to 4-Pin Wire.

Assemble the following components
Effect diagram after assembling
3-Pin Wire x1
For convenience to read, 3-Pin Wire will be only
shown the connector part in the following section.
4-Pin Wire x1
OLED x1
For convenience to read, 4-Pin Wire will be only
shown the connector part in the following section.
