G. Fix A05 with the servo on A04
Assemble the following components
M2.5*8
screw packaged
Screw x1
with servo
H. Fix A05 with the servo on A06.
Assemble the following components
Self-tapping
screw packaged
x1
with servo
Repeat steps E to H and connect the other two components C2 and two components D2.
A04
A05 x1
Self-tapping
x1
A06
M2.5*8
Screw x1
Effect diagram after assembling
Effect diagram after assembling
