Assemble the upper part
A. Keep the four M3*6 Copper Standoffs fixed on A01
Assemble the following components
M3*6 Copper Standoff x4
A01 x1
M3*5 Screw x4
Effect diagram after assembling
www.adeept.com
M3*6 Copper Standoff is at
the same side with LOGO
For the convenience of reading,
here the Acrylic Sheets is
colorized; in this manual Acrylic
Sheets' color depends on the
reality
11
