2.Assembly
2.1.Preparations before Assembly
1.Connect the Raspberry Pi Camera and the ribbon.
Assemble the following components
Raspberry Pi Camera x1
Effect diagram after assembling
2.Connect the Adeept Ultrasonic Module with 4-Pin wire.
Assemble the following components
Effect diagram after assembling
Raspberry Pi Camera Ribbon x1
Adeept Ultrasonic Module x1
4-Pin wire x1
