2.Assembly

2.1.Preparations before Assembly

1.Connect the Raspberry Pi Camera and the ribbon.
Assemble the following components
Raspberry Pi Camera x1
Effect diagram after assembling
2.Connect the Adeept Ultrasonic Module with 4-Pin wire.
Assemble the following components
Adeept Ultrasonic Module x1
4-Pin wire x1
Effect diagram after assembling
6
Raspberry Pi Camera Ribbon x1
