www.adeept.com
H. Take a Servo and install on A01
Assemble the following components
M2*8 Screw
x2
Servo x1
Effect diagram after assembling
The rotation axis of servo is
on the right as the picture
shown.
18
M2 Nut x2
After the completion of the
assembly, the wiring of the steering
gear across through this hole
