program, when the IO voltage connected to the user LED light is high, the user

LED light is off, when the connection IO voltage is low, the user LED will be

illuminated. The schematic diagram of the LED light hardware connection is shown

in Figure 2-8-1:

Figure 2-8-1: The schematic diagram of the LED light hardware connection

23 / 60

ZYNQ FPGA Development Platform AX7015 User Manual

BANK

500

ZYNQ

BANK

2-8-2: LED light on the Core Board

Figure

Amazon Store: https://www.amazon.com/alinx

3.3V

PWR

LED1

LED2

3.3V

DONE
