Alinx KINTEX-7 FPGA User Manual page 23

J29 connector pin assignment
J29 Pin Signal Name
1 BANK115_TX0_N
3 BANK115_TX0_P
5
7 BANK115_TX1_N
9 BANK115_TX1_P
11
13 BANK115_TX2_N
15 BANK115_TX2_P
17
19 BANK115_TX3_N
21 BANK115_TX3_P
23
25 BANK115_CLK0_N
27 BANK115_CLK0_P
29
31 BANK116_TX0_N
33 BANK116_TX0_P
35
37 BANK116_TX1_N
39 BANK116_TX1_P
41
43 BANK116_TX2_N
45 BANK116_TX2_P
47
49 BANK116_TX3_N
51 BANK116_TX3_P
53
55 BANK116_CLK0_N
57 BANK116_CLK0_P
23 / 45
KINTEX-7 FPGA Development Board AV7K300 User Manual
FPGA Pin
Y1
Y2
GND -
V1
V2
GND -
U3
U4
GND -
T1
T2
GND -
R7
R8
GND -
P1
P2
GND -
N3
N4
GND -
M1
M2
GND -
L3
L4
GND -
L7
L8
