GTX Clock Source FPGA pin assignments:
BANK117_CLK1_P
BANK117_CLK1_N

Part 2.6: LED Light

There are 2 red LED lights on the AC7K325 core board, one of which is
the power indicator (PWR) and the other is the configuration LED (DONE). The
power indicator will light up; after the FPGA configuration program, the
configuration LED light will light up. The schematic diagram of LED light
hardware connection is shown in Figure 2-6-1:
18 / 45
KINTEX-7 FPGA Development Board AV7K300 User Manual
Figure 2-5-3: GTX Clock Source
Signal Name
Amazon Store: https://www.amazon.com/alinx
FPGA Pin
J8
J7
