Part 2.2: FPGA Chip

The FPGA development board uses Xilinx's KINTEX-7 FPGA chip, model
number XC7K325T-2FFG900I. The speed class is 2 and the temperature class
is industrial. This model is a FGG900 package with 900 pins and a 1.0mm pitch.
The chip naming rules for Xilinx KINTEX-7 FPGA are shown in Figure 2-2-1
below:
Figure 2-2-1: The Specific Chip Model Definition of KINTEX-7 Series
Figure 2-2-2: FPGA chip XC7K325T on board
The main parameters of the FPGA chip XC7K325T are as follows
CLB flip-flops
9 / 45
KINTEX-7 FPGA Development Board AV7K300 User Manual
Name
Logic Cells
Slices
Amazon Store: https://www.amazon.com/alinx
Specific parameters
326,080
50,950
407,600
