User Guide V
IU 6400-S Converged Network Appliance
4 - 8
2. In the System menu, select Set Link.
3. Select Subscriber Ethernet or Provider Ethernet.
4. Select the appropriate link rate for your Ethernet network (Note: If you
set either 6400-S interfaces to 100FD, be sure you set the device at the
other end of the line to 100FD also.):
Setting
10baseT-HD
10baseT-FD
100baseT-HD
100baseT-FD
Autonegotiate
5. Press Submit.
Description
10Mbits per second using half duplex
transmission
10Mbits per second using full duplex
transmission
100Mbits per second using half duplex
transmission
100Mbits per second using full duplex
transmission
The 6400-S autonegotiates link rate and
duplex with the directly attached device.
