Basic settings rules
Configuring Advanced Firewall Settings
Follow these rules when configuring basic settings:
•
For Allow TCP Port and Allow UDP Port, valid values are 1 through
65535.
•
Separate multiple entries by spaces,
•
Indicate a range of values with a colon (:). For example, 25:50 means
perform the action on ports 25 through 50
A comprehensive security policy can be created using advanced settings.
To configure advanced settings:
1. In the navigation pane, select Firewall and scroll to Advanced LAN and
WAN Firewall Settings.
2. Enable to disable firewall logging. (See
on page 6-4.)
3. Configure Deny Hosts (IP) according to the rules in
rules
on page 6-4. Deny Hosts (IP) denies all traffic with the source IP
address matching the specified hosts
Configuring the Firewall
Enabling or disabling the firewall
Advanced setting
6 - 3
