9
2
70D N/B Maintenance
9
2
70D N/B Maintenance
SERVICE MANUAL FOR
SERVICE MANUAL FOR
SERVICE MANUAL FOR
9270D
9270D
9270D
BY: Wenrong.pu
Technical Maintenance Department/GTK MTC
Jan. 2010/R01
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 9270D and is the answer not in the manual?

Questions and answers

Related Manuals for Getac 9270D

Summary of Contents for Getac 9270D

  • Page 1 70D N/B Maintenance 70D N/B Maintenance SERVICE MANUAL FOR SERVICE MANUAL FOR SERVICE MANUAL FOR 9270D 9270D 9270D BY: Wenrong.pu Technical Maintenance Department/GTK MTC Jan. 2010/R01...

  • Page 2: Table Of Contents

    Contents 1. Hardware Engineering Specification ……………………………………………………………………. 1.1 Introduction ……………………………………………………………………………………………………………… 1.2 System Hardware Parts………………………………………………………………………………………………….. 1.3 Other Function ………………………………………………………………………………………...………………..1.4 Peripheral Components ………………………………………………………………………………………………… 1.5 Power Management ………………………………………………………………………………………...…………… 1.6 Appendix ………………………………………………………………………………………...………………..…..2. System View and Disassembly …………………………………………………………………………..2.1 System View ……………………………………………………………………………………………………………… 2.2 Tools Introduction …………………………………………………………………………………………………..…… 2.3 System Disassembly ………………………………………………………………………………………………………...
  • Page 3 Contents 6. Trouble Shooting …………………………………………………………………………………………. 6.1 No Power …………………………………………………………………………………………………....... 6.2 No Display …………………………………………………………………………………………………..... 6.3 Graphics Controller Failure LCD No Display ……………………………………………………………………….. 6.4 External Monitor No Display ………………………………………………………………………………………….. 6.5 Memory Failure ………………………………………………………………………………………………….... 6.6 Keyboard (K/B) or Touch-Pad (T/P) Failure ………………………………………………………………………..6.7 Hard Disk Drive Failure ……………………………………………………………………………………………….. 6.8 ODD Failure …………………………………………………………………………………………………....

  • Page 4: Hardware Engineering Specification

    1. Hardware Engineering Specification 1.1 Introduction The 9270D motherboard implements Intel’s Calpella platform with Arrandale mobile processor. Arrandale is the next generation of 64-bit, multi-core mobile processors built on 32-nanometer process technology. Throughout this document, Arrandale may be referredto as simply the processor. Based on the low-power/high-performance Nehalem microarchitecture, the processor is designed for a two-chip platform as opposed to the traditional three- chip platforms (processor, GMCH, and ICH).
  • Page 5 Integrated Serial ATA host controllers with independent DMA operation on up to six ports. FIS-based Port Multiplier support on SATA Ports 4 and 5 in AHCI/RAID mode. USB host interface with support for up to fourteen USB ports; two EHCI high-speed USB 2.0 Host controllers, 2 rate matching hubs, seven UHCI host controllers;...
  • Page 6 Intel® Quiet System Technology (Desktop only) Intel® Anti-Theft Technology User expendable peripheral interface built on 9270D system are 3 USB + 1 combo E-SATA ports. 9270D system provides a New Card / Express Card and Mini PCI-E Card. User interface includes internal keyboard, touch pad.

  • Page 7: System Hardware Parts

    1.2 System Hardware Parts-1 Basic Function Spec Remark Type Intel Arrandale CPU 45/35W (Processor/chipset SOC) Display 18.4 SWXGA + Glare/Non Glare 1680x945 HD+ -Max Brightness :TBD 1920x1080 FHD Chipset Ibex Peak Chipset Memory 0 MB on board Type DDRIII SO-DIMM 1066/1333 MHz Slot 2 SO-DIMM Max Size...
  • Page 8 1.2 System Hardware Parts-2 Spec Basic Function Remark Express Card Slot Type Express 54 x1 USB & PCI-E Function Wake on ring support To be able to disable by BIOS Card Reader 4 in 1 Card Reader Slot Type MS / MS PRO / SD / MMC Access LED Function SDHC Support...
  • Page 9 1.2.1 Intel Arrandale CPU Processor 1.2.1.1 CPU – Intel Arrandale Arrandale Processor Introduction Arrandale is the next generation of 64-bit, multi-core mobile processor built on 32- nanometer process technology. Throughout this document, Auburndale may be referred to as simply the processor. Based on the low-power/high-performance Nehalem micro-architecture, the processor is designed for a two-chip platform as opposed to the traditional three-chip platforms (processor, GMCH, and ICH).
  • Page 10 Up to 8-MB shared instruction/data last-level cache (L3), shared among all cores Intel® Virtualization Technology (Intel® VT-x) Intel® Virtualization Technology for Directed I/O (Intel® VT-d) Intel® Trusted Execution Technology (Intel® TXT) Intel® Streaming SIMD Extensions 4.1 (Intel® SSE4.1) Supplemental Streaming SIMD Extensions 4.2 (Intel® SSE4.2) Intel®...
  • Page 11 1.2.1.2 Mobile Intel Arrandale system memory support The Integrated Memory Controller (IMC) supports DDR3 protocols with two, independent, 64-bit wide channels each accessing one SO-DIMM. It supports a maximum of one, unbuffered non-ECC DDR3 SO-DIMM per- channel thus allowing up to two device ranks per-channel. DDR3 Data Transfer Rates: — 800 MT/s (PC3-6400), and 1066 MT/s (PC3-8500) DDR3 SO-DIMM Modules: —...
  • Page 12 System Memory Timing Support The IMC supports the following DDR3 Speed Bin, CAS Write Latency (CWL), and command signal mode timings on the main memory interface: tCL = CAS Latency tRCD = Activate Command to READ or WRITE Command delay tRP = PRECHARGE Command Period CWL = CAS Write Latency Command Signal modes = 1n indicates a new command may be issued every clock and 2n indicates a new...
  • Page 13 1.2.2 Intel Platform control HUB Ibex Peak chipset 1.2.2.1 Introduction Direct Media Interface —10 Gb/s each direction, full duplex —Transparent to software PCI Express* —NEW: 8 PCI Express root ports —NEW: PCI Express 2.0 specification running at 2.5GT/s. —NEW: Ports 1-4 and 5-8 can independently be configured to support eight x1s, two x4s, two x2s and four x1s, or one x4 and four x1 port widths.
  • Page 14 PCI Bus Interface —Supports PCI Rev 2.3 Specification at 33 MHz —Four available PCI REQ/GNT pairs —Support for 64-bit addressing on PCI using DAC protocol Integrated Serial ATA Host Controller —Up to six SATA ports —Data transfer rates up to 3.0 Gb/s (300 MB/s). —Integrated AHCI controller External SATA support —NEW: Port Disable Capability...
  • Page 15 —Supports variable length stream slots —Supports multichannel, 32-bit sample depth, 192 kHz sample rate output —Provides mic array support —Allows for non-48 kHz sampling output —Support for ACPI Device USB 2.0 —NEW: Two USB 2.0 Rate Matching Hubs to replace functionality of UHCI controllers —Two EHCI Host Controllers, supporting up to fourteen external ports —Per-Port-Disable Capability —Includes up to two USB 2.0 High-speed Debug Ports...
  • Page 16 Integrated Gigabit LAN Controller —NEW: PCI Express* connection —Integrated ASF Management Controller —Network security with System Defense —Supports IEEE 802.3 —10/100/1000 Mbps Ethernet Support —Jumbo Frame Support Power Management Logic —Supports ACPI 3.0b —ACPI-defined power states (processor driven C states) —ACPI Power Management Timer —SMI# generation —All registers readable/restorable for proper resume from 0 V suspend states...
  • Page 17 Enhanced DMA Controller —Two cascaded 8237 DMA controllers —Supports LPC DMA SMBus —Faster speed, up to 100 kbps —Flexible SMBus/SMLink architecture to optimize for ASF —Provides independent manageability bus through SMLink interface —Supports SMBus 2.0 Specification —Host interface allows processor to communicate via SMBus —Slave interface allows an internal or external Microcontroller to access system resources —Compatible with most two-wire components that are also I2C compatible High Precision Event Timers...
  • Page 18 Real-Time Clock —256-byte battery-backed CMOS RAM —Integrated oscillator components —Lower Power DC/DC Converter implementation Serial Peripheral Interface (SPI) —Supports up to two SPI devices —Supports 20 MHz, 33 MHz SPI devices —Support up to two different erase granularities Interrupt Controller —Supports up to eight PCI interrupt pins —Supports PCI 2.3 Message Signaled Interrupts —Two cascaded 82C59 with 15 interrupts...
  • Page 19 Firmware Hub I/F supports BIOS Memory size up to 8 MBytes Low Pin Count (LPC) I/F —Supports two Master/DMA devices. —Support for Security Device (Trusted Platform Module) connected to LPC. Package —27 mm x 27 mm FCBGA (Desktop Only) —27 mm x 25 mm FCBGA (Mobile Only) —22 mm x 20 mm FCBGA (Mobile SFF Only) Analog Display Port Digital Display...
  • Page 20 1.2.2.2 Features and Functions Digital Media Interface (DMI) Digital Media Interface (DMI) is the chip-to-chip connection between the processor and Ibex Peak chipset. This high-speed interface integrates advanced priority-based servicing allowing for concurrent traffic and true isochronous transfer capabilities. Base functionality is completely software-transparent, permitting current and legacy software to operate normally.
  • Page 21 PCI Interface The Ibex Peak PCI interface provides a 33 MHz, Revision 2.3 implementation. The Ibex Peak integrates a PCI arbiter that supports up to four external PCI bus masters in addition to the internal Ibex Peak requests. This allows for combinations of up to four PCI down devices and PCI slots.
  • Page 22 Note: UHCI’s are for debug purposes only and not a production feature. The Ibex Peak supports up to fourteen USB 2.0 ports. All fourteen ports are highspeed, full-speed, and low-speed capable. Ibex Peak’s port-routing logic determines whether a USB port is controlled by one of the UHCI or EHCI controllers.
  • Page 23 read and write accesses. This prevents unauthorized reading of passwords or other system security information. The RTC also supports a date alarm that allows for scheduling a wake up event up to 30 days in advance, rather than just24 hours in advance. Intel®...
  • Page 24 ATI M96 series 1.2.3 GDDR3 1Gb (64Mx16) – K4W1G1646E VDD/VDDQ= 1.5V ± 0.075V at 1066/1333/1600/1800/2000 533MHz fCK for 1066Mb/sec/pin, 667MHz fCK for 1333Mb/sec/pin, 800MHz fCK for 1600Mb/sec/pin 900MHz fCK for 1800Mb/sec/pin,1000MHz fCK for 2000Mb/sec/pin 8 Banks Posted CAS Programmable CAS Latency(posted CAS): 7,9,11,12,13 Programmable Additive Latency: 0, CL-2 or CL-1 clock Programmable CAS Write Latency: (CWL) =6 (1066Mbps), 7(1333Mbps), 8(1600Mbps), 9(1800Mbps),10(2000Mbps)
  • Page 25 • Average Refresh Period: 7.8us at lower than TCASE 85°C, 3.9us at 85°C < TCASE < 95 °C • Asynchronous Reset • Package : 96 balls FBGA - x16 • All of Lead-Free products are compliant for RoHS • All of products are Halogen-Freetr 1.2.4 Realtek ALC633 High Definition Audio System The ALC663 is a 5.1 Channel High Definition Audio Codec designed for Windows system.
  • Page 26 Multiple analog IO (except MONO, PCBEEP and HP-OUT) are input and output capable with headphone amplifiers. Four linear headphone amplifiers are integrated to drive earphones on port-A, port-D, port-E and port-F. The fifth headphone amplifier on port-I (HPOUT) is designed to drive earphone without external DC blocking capacitors, reducing pop noise caused by the DC blocking capacitors.
  • Page 27 1.2.5 APA2031 Audio Amplifier and APA3010 subwoofer APA2031 APA2030/1 is a monolithic integrated circuit, which provides internal gain control, and a stereo bridged audio power amplifiers capable of producing 2.6W (1.9W) into 3Ω with less than 10% (1.0%) THD+N. By control the two gain setting pins, Gain0 and Gain1, The amplifier can provide 6dB, 10dB, 15.6dB, and 21.6dB gain settings.
  • Page 28 Low Distortion –2.5W, at VDD=5V, BTL, RL=3W THD+N=0.1% –2.1W, at VDD=5V, BTL, RL=4W THD+N=0.1% Output Power at 1% THD+N –2.6W, at VDD=5V, BTL, RL=3W –2.3W, at VDD=5V, BTL, RL=4W at 10% THD+N –3.3W at VDD=5V, BTL, RL=3W –2.7W at VDD=5V, BTL, RL=4W Depop Circuitry Integrated Thermal shutdown protection and over current protection circuitry...
  • Page 29 High supply voltage ripple rejection Surface-Mount Packaging –MSOP-8-P (with enhanced thermal pad) –SOP-8-P (with enhanced thermal pad) Lead Free Available (RoHS Compliant) 1.2.6 Keyboard System – IT8512 Universal Keyboard Controller 8032 Embedded Controller - Twin Turbo version/3-stage pipeline - 9.2 MHz for EC domain and 8032 internal timer - Variable frequency range to gain the maximum 8032 code-fetch performance -Instruction set compatible with standard 8051/2 LPC Bus Interface...
  • Page 30 - Supports Memory read/write - Supports FWH read/write -Serial IRQ Flash Interface - Behaves as a LPC/FWH memory device (HLPC) to the host SouthBridge - Supports external serial flash with 32.3~64.5 - Up to 16M bytes Flash space shared by the host and EC side (serial flash) SM Bus Controller - SM Bus spec.
  • Page 31 System Wake Up Control - Modem RI# wake up - Telephone RING# wake up - IRQ/SMI routing EC Wake Up Control - 40 external/internal wake up events Interrupt Controller - 48 interrupt events to EC - Fixed priority Timer / Watch Dog Timer - 3 16-bit multi-function timers inside 8032, which is based on EC clock - 1 watch dog timer inside 8032, which is based...
  • Page 32 - 1 external WDT in ETWD module, which is based on 32.768 k clock source UART -1 full duplex UART inside 8032 ACPI Power Management Channel - 2 Power management channels - Compatible and enhanced mode Battery-backed SRAM - Supports 64-byte battery-backed memory space - Supports power-switch circuit GPIO...
  • Page 33 External GPIO Controller (EGPC) - Communicate with 4 IT8301 chips -Each IT8301 supports 38 GPIO ports KBC Interface - 8042 style KBC interface - Legacy IRQ1 and IRQ12 - Fast A20G and KB reset - 12 ADC channels (8 external) - 10-bit resolution (+/- 4LSB) - Digital filter for noise reduction - 6 DAC channels...
  • Page 34 - 8 PWM channels - Base clock frequency is 32.768 kHz - 8 duty cycle resolution - 8/16-bit common input clock prescaler - 4 prescalers for 8 PWM output used for devices with different frequencies - 2 Tachometers for measuring fan speed - Complete resolution 256 PWM output supported.
  • Page 35 KB Matrix Scan - Hardware keyboard scan - 18x8 keyboard matrix scan 1.2.7 System SPI Flash Memory (BIOS) –EN25F16 The EN25F16 is a 16M-bit (2048K-byte) Serial Flash memory, with advanced write protection mechanisms, accessed by a high speed SPI-compatible bus. The memory can be programmed 1 to 256 bytes at a time, using the Page Program instruction.
  • Page 36 Low power consumption - 5 mA typical active current - 1 μA typical power down current Uniform Sector Architecture: - 512 sectors of 4-Kbyte - 32 blocks of 64-Kbyte - Any sector or block can be erased individually Software and Hardware Write Protection: - Write Protect all or portion of memory viasoftware - Enable/Disable protection with WP# pin High performance program/erase speed...
  • Page 37 Lockable 256 byte OTP security sector Minimum 100K endurance cycle Package Options - 8 pins SOP 200mil body width - 8 contact VDFN - 8 pins PDIP - 16 pin SOP 300mil body width - All Pb-free packages are RoHS compliant 1.2.8 Card Reader - RTS5159 The RTS5159 is an ultimate throughput USB 2.0 compliant card reader controller that integrates USB 2.0 Transceiver, MCU, SIE, regulators and memory card access units into a single chip.
  • Page 38 The RTS5159 integrates 3.3V-to-1.8V regulator, clock generation circuitry and MOSFET, and could dramatically reduce the system BOM cost. Compliant with Universal Serial Bus Specification Revision 2.0 Compliant with USB Mass Storage Class Bulk only Transport Specification Rev. 1.0 Support High-speed (480Mbps) and Full-speed (12Mbps) Data Transfer USB bus power operation Support Control, Bulk IN / OUT data pipes Support the following memory card interfaces:...
  • Page 39 Support hardware CRC (Cyclic Redundancy Check) function Programmable clock rate for flash memory card interfaces Support MS-PRO v1.02 Support MS v1.43 Support MS PRO-HG Duo v1.01 Support SD version 2.0 Support MMC version 4.2...
  • Page 40 1.2.10 RGMII LAN PHY - RTL8111D The Realtek RTL8111D-GR/RTL811DL-GR Gigabit Ethernet controller combines a triple-speed IEEE 802.3 compliant Media Access Controller (MAC) with a triple-speed Ethernet transceiver, PCI Express bus controller, and embedded memory. With state-of-the-art DSP technology and mixed-mode signal technology, the RTL8111D/RTL8111DL offers high-speed transmission over CAT5 UTP cable or CAT3 UTP (10Mbps only) cable.

  • Page 41: Other Function

    1.3 Other Function 1.3.1 Hot Key Function Keys Feature Meaning Combination Fn + F1 Wireless LAN ON/OFF Enable or Disable Wireless LAN Function Fn + F2 Bluetooth ON/OFF Enable or Disable Bluetooth Function Fn + F3 Volume down Audio Volume down Fn + F4 Volume up Audio Volume up...
  • Page 42 1.3.2 Power on/off/Suspend/Resume Button 1.3.2.1 APM Mode At APM mode, Power button is on/off system power. 1.3.2.2 ACPI Mode At ACPI mode, Windows power management control panel set power button behavior. You could set "standby", "power off" or "hibernate"(must enable hibernate function in power Management) to power button function.
  • Page 43 2. Standby 3. Off 4. Hibernate (must enable hibernate function in power management 1.3.4 LED Indicators System has six status LED indicators to display system activity, which include six above Front Bezel and MMB LED indicators.
  • Page 44 1.3.4.1 Six LED Indicators System State LED Indicators Definition S1/S2 Location 　 Front Bezel function status Battery Charge LED Battery Full Charged Left 1 Battery charging Blue Blue Blue Blue Battery Critical Low Blue Blink Blue Blink Blue Blink Blue Blink Wlan WLAN Enable Blue...
  • Page 45 1.3.5 Battery status 1.3.5.1 Battery Warning System also provides Battery capacity monitoring and gives user a warning so that users have chance to save his data before battery dead. Also, this function protects system from mal-function while battery capacity is low. Battery Warning: Capacity below 10%, Battery Capacity LED flashes per second, system beeps per 2 seconds.
  • Page 46 1.3.6 Fan Power on/off Management 1.3.6.1 CPU Fan FAN is controlled by W83L951AD embedded controller-using F75385 to sense CPU temperature and W83L951AD PWM control fan speed. Fan speed is depended on CPU temperature. Higher CPU temperature will get faster Fan Speed.

  • Page 47: Peripheral Components

    1.4 Peripheral Components 1.4.1 LCD Panel 18.4 SWXGA + Glare/Non Glare 1.4.2 HDD SATA I/F, 2.5” 9.5mm height HDD 80/100/120/160 GB, CBB 1.4.3 ODD SATA I/F, 12.7mm height ODD Super Multi/BlueRay...
  • Page 48 1.4.4 DDR SO-DIMM 0MB DDRII SDRAM memory on board 2 SO- DIMM slots for memory expansion 200pin DDRIII 800 1/2/4GB SDRAM SO-DIMM Memory Module 1.4.5 Keyboard European keyboard layout 18.45mm key pitch / 2.6mm stroke...

  • Page 49: Power Management

    1.5 Power Management The 9270D system has built in several power saving modes to prolong the battery usage. User can enable and configure different degrees of power management modes via ROM CMOS setup (booting by pressing F2 key). Following are the descriptions of the power management modes supported.
  • Page 50 - LCD: backlight off - HDD: spin down Suspend to DRAM The most chipset of the system is entering power down mode for more power saving. In this mode, the following is the status of each device: -- CPU: off -- Twister K: Partial off -- VGA: Suspend -- New Card: Suspend...
  • Page 51 1.5.2 Battery Only Power off Mode The 9270D system has built in Battery only power off mode to prolong the battery usage. In this mode, Universal Keyboard Controller (KBC) will be power off. In addition, the system leakage current shall be less than 0.5mA;...

  • Page 52: Appendix

    1.6 Appendix 1.6.1 IBEX PEAK-M GPIO Setting Table-1 Name Type Power well Tolerance Default Original Define HW Function BMBUSY#/GPIO0 GPIO0 GPIO0 Core GPIO1 Core TACH1/GPIO1 EXTSMI# GPIO2 I/OD Core PIRQE#/GPIO2 PCI_INTPIRQE# GPIO3 I/OD Core PIRQF#/GPIO3 PCI_INTPIRQF# GPIO4 I/OD Core PIRQG#/GPIO4 PCI_INTPIRQG# GPIO5 I/OD...
  • Page 53 1.6.1 IBEX PEAK-M GPIO Setting Table-2 Name Type Power well Tolerance Default Original Define HW Function GPIO19 Core SATA1GP/GPIO19 GPIO19 GPIO20 Core Native PCIECLKRQ2#/GPIO20 PEB_CLKREQ_NEWCARD# GPIO21 Core SATA0GP/GPIO21 BT_ON# GPIO22 Core SCLOCK/GPIO22 BIOS_REC GPIO23 Core Native LDRQ1#/GPIO23 Reserve GPIO24 Resume GPIO24 SB_MUTE# GPIO25...
  • Page 54 1.6.1 IBEX PEAK-M GPIO Setting Table-3 Name Type Power well Tolerance Default Original Define HW Function GPIO38 Core SLOAD/GPIO38 MFG_MODE GPIO39 Core SDATAOUT0/GPIO39 CRB_SV_DET GPIO40 Resume Native USB_OC#1/GPIO40 Reserve GPIO41 Resume Native USB_OC#2/GPIO41 USB_OC#2 GPIO42 Resume Native USB_OC#3/GPIO42 USB_OC3# GPIO43 Resume Native USB_OC#4/GPIO43...
  • Page 55 1.6.1 IBEX PEAK-M GPIO Setting Table-4 Name Type Power well Tolerance Default Original Define HW Function GPIO57 Resume GPIO57 GPIO57 GPIO58 Resume Native SML1CLK/GPIO58 SMBCLK_PCH_KBC GPIO59 Resume Native USB_OC#0/GPIO59 USB_OC0# GPIO60 Resume Native SML0ALERT#/GPIO60 GPIO60 Resume Native SUS_STAT#/GPIO61 LPC_PD# GPIO61 Resume Native SUSCLK/GPIO62...
  • Page 56 1.6.2 KBC IT8512 GPIO Setting Table-1 Pin no Signal 9270D PWM0/GPA0 LED_CAP# PWM1/GPA1 LED_NUM# PWM2/GPA2 LED_CHARGER# PWM3/GPA3 LED_BATT_R# PWM4/GPA4 RESERVE PWM5/GPA5 KBC_BEEP PWM6/GPA6 FAN_ON PWM7/GPA7 KBC_BLADJ RXD/GPB0 KBC_RX TXD/GPB1 KBC_TX CTX0/GPB2 SUSB_1.8VS SMCLK0/GPB3 BAT_CLK SMDAT0/GPB4 BAT_DATA GA20/GPB5 KBC_A20GATE KBRST#/GPB6 KBC_RCIN#...
  • Page 57 1.6.2 KBC IT8512 GPIO Setting Table-2 Pin no Signal 9270D LPCRST#/WUI4/GPD2 BUF_PLT_RST# ECSCI#/GPD3 KBC_SCI# ECSMI#/GPD4 KBC_EXTSMI# GINT/GPD5 KBC_ENABKL TACH0/GPD6 FAN_SPD TACH1/GPD7 SB_PWRGD_KBC L80HLAT/GPE0 SW_VDD3 EGAD/GPE1 PWRON_VDD3S EGCS#/GPE2 SUSB_0.75VS EGCLK/GPE3 SUSC_3V PWRSW/GPE4 PWRBTN# WUI5/GPE5 BAT_TEMP LPCPD#/WUI6/GPE6 LPC_PD# L80LLAT/WUI7/GPE7 RESERVE PS2CLK0/GPF0 TP_CLK...
  • Page 58 1.6.2 KBC IT8512 GPIO Setting Table-3 Pin no Signal 9270D CLKRUN#/WUI16/GPH0/ID0 PM_CLKRUN# CRX1/WU117/GPH1/ID1 LID_SW# CTX1/WUI18/GPH2/ID2 SUSC_1.5V WUI19/GPH3/ID3 SUSB_VGA GPH4/ID4 CHARGING GPH5/ID5 SUSB_CPU_CORE GPH6/ID6 LEARNING ADC0/GPI0 BAT_VOLT ADC1/GPI1 ADC2/GPI2 ADC3/GPI3 I-LIMIT ADC4/GPI4 KBC_MB_ID_0 ADC5/GPI5 KBC_MB_ID_1 ADC6/GPI6 +KBC_CPUCORE ADC7/GPI7 DAC0/GPJ0 I_CTRL DAC1/GPJ1...
  • Page 59 1.6.2 KBC IT8512 GPIO Setting Table-4 Pin no Signal 9270D LAD3 LPC_AD3 LAD2 LPC_AD2 LAD1 LPC_AD1 LAD0 LPC_AD0 +3VS LPCCLK CLK_PCI_KBC WRST# KBC_RESET# VSTBY +VDD3 KSO0/PD0 KSO1/PD1 KSO2/PD2 KSO3/PD3 KSO4/PD4 KSO5/PD5 KSO6/PD6 KSO7/PD7 KSO8/ACK# KSO9/BUSY KSO10/PE KO10 VSTBY +VDD3 KSO11/ERR#...
  • Page 60 1.6.2 KBC IT8512 GPIO Setting Table-5 Pin no Signal 9270D KSO14 KO14 KSO15 KO15 KSI0/STB# KSI1/AFD# KSI2/INIT# KSI3/SLIN# KSI4 KSI5 KSI6 KSI7 AVCC +VDD3_ALW AVSS ITE_GND VSTBY +VDD3 FSCE# KBC_SPI_SCSI# FMOSI KBC_SPI_MOSI FMISO KBC_SPI_MISO FSCK KBC_SPI_SCK VSTBY +VDD3 VSTBY +VDD3...
  • Page 61 1.6.3 9270D Product Spec-1 ITEM CATEGORY DESCRIPTION Type Intel Capella PM Package 45/35W (Processor/chipset SOC) Socket Socket-P Speed Others Assembling Capability Distribution configurable Brand Phoenix Size of EEPROM System BIOS BIOS Architecture Others Brand & Model Name: North None Bridge Chipset Brand &...
  • Page 62 1.6.3 9270D Product Spec-2 ITEM CATEGORY DESCRIPTION Type (UMA or Discrete) Discrete Interface PCI-E VIDEO Brand & Model Name ATI M96-M2 Pro+ CONTROLLER Marketing Name ATI Mobility Radeon™ HD 4650 Others 128bit memory bus/ No TV Out Type gDDRIII No. of Vram Chips...
  • Page 63 1.6.3 9270D Product Spec-3 ITEM CATEGORY DESCRIPTION Size 18.4"W Type DISPLAY Resolution 1680x945 HD+ 1920x1080 FHD Others Height 5.6mm Pitch 18.45mm Stroke 2.6mm KEYBOARD Width 339mm Layout US/UI Others Type Underplastic touchpad without scroll bar POINTING Number of Button DEVICE...
  • Page 64 1.6.3 9270D Product Spec-4 ITEM CATEGORY DESCRIPTION Ejection Type Memory Card Type of Card Support SD/MS/MS Pro/MMC Reader Others 3 (USB 2.0) USB/e-SATA RJ-11 RJ-45 Headphone S/PDIF Microphone Line In DC Input Analog VGA Port I/O Port DVI-D DVI-I S-Video Out...
  • Page 65 1.6.3 9270D Product Spec-5 ITEM CATEGORY DESCRIPTION Number of Quick Key Quick Key Definition Number of Indicator Indicator WLAN/BT/power/battery charge/cap Definition lock/num lock/HDD & ODD Interface Type & Speed Modem Form Factor Assembling Capability Others Interface LAN Phy Speed 10/100/1000 Mbps...
  • Page 66 1.6.3 9270D Product Spec-6 ITEM CATEGORY DESCRIPTION Type Li-Ion Cylinder Number of Cell 9 cell Battery Pack Capacity 6600mAH/11.1V (9 cell) Battery Life Assembling Capability user Swappable Type Universal AC adaptor Wattage 90W/120W Input Voltage 100V ~ 240V AC Adapter...
  • Page 67 1.6.3 9270D Product Spec-7 ITEM CATEGORY DESCRIPTION Microsoft LOGO Windows Logo Vista Premium SP1 Windows 7 Regulation Safety Green Product ROHS Coverage...

  • Page 68: System View And Disassembly

    2. System View and Disassembly 2.1 System View 2.1.1 Left-side View Kensington Lock CRT Connector RJ45 Connector HDMI Connector ESATA+USB Connector USB Ports Card Reader Connector Express Card Connector...
  • Page 69 2.1.2 Right-side View Headphone out MIC In SPDIF Connector USB Port Power Jack 2.1.3 Rear View Ventilation Openings...
  • Page 70 2.1.4 Bottom View CPU & DDR3 SO-DIMM & Mini Express Card Battery Park 2.1.5 Top-open View LCD Screen Power Button Internal MIC ○ Touch Pad ○ Keyboard Speaker Web Camera...

  • Page 71: Tools Introduction

    2.2 Tools Introduction 1. Minus screw driver for notebook assembly & disassembly. 2 mm 2 mm 2. Auto screw driver for notebook assembly & disassembly. Bit Size Screw Size Tooling Tor. Bit Size 1. M2.0 Auto-Screw driver 2.0-2.5 kg/cm...

  • Page 72: System Disassembly

    2.3 System Disassembly The section discusses at length each major component for disassembly/reassembly and show corresponding illustrations.Use the chart below to determine the disassembly sequence for removing components from the notebook. NOTE: Before you start to install/replace these modules, disconnect all peripheral devices and make sure the notebook is not turned on or connected to AC power.
  • Page 73 2.3.1 Battery Pack Disassembly 1. Carefully put the notebook upside down. 2. Slide two release lever outwards to the “unlock” ( ) position ( ), while take the battery pack out of the compartment ( ). (Figure 2-1) Figure 2-1 Remove the battery pack Reassembly 1.
  • Page 74 2.3.2 CPU Disassembly 1. Remove the battery pack. (Refer to section 2.3.1 Disassembly) 2. Remove eight screws fastening the CPU cover. (Figure 2-2) 3. Remove six spring screws that secure the heatsink upon the CPU and remove three screws fastening the fan, then disconnect the fan’s power cord from system board.
  • Page 75 4. To remove the existing CPU, loosen the screw by a flat screwdriver,upraise the CPU socket to unlock the CPU. (Figure 2-4) Figure 2-4 Remove the CPU Reassembly 1. Carefully, align the arrowhead corner of the CPU with the beveled corner of the socket, then insert CPU pins into the holes.
  • Page 76 2.3.3 DDR3-SDRAM Disassembly 1. Carefully put the notebook upside down. Remove the battery pack. (See section 2.3.1 Disassembly) 2. Remove eight screws fastening the CPU cover. (Refer to step 2 of section 2.3.2 Disassembly) Figure 2-5 Remove the SO-DIMM 3. Pull the retaining clips outwards ( ) and remove the SO-DIMM ( ). (Figure 2-5) Reassembly 1.
  • Page 77 2.3.4 HDD Disassembly 1. Carefully put the notebook upside down. Remove the battery pack and . (Refer to section 2.3.1 Disassembly) 2. Remove two screws fastening the HDD cover. (Figure 2-6) 3. Lift the HDD module out and disconnect the HDD connector. (Figure 2-7) Figure 2-7 Remove HDD module Figure 2-6 Remove HDD cover Reassembly...
  • Page 78 2.3.5 ODD Disassembly 1. Carefully put the notebook upside down. Remove the battery pack. (Refer to section 2.3.1 Disassembly) 2. Remove one screw fastening the ODD. (Figure 2-9) 3. Insert a small rod, such as a straightened paper clip, into ODD’s manual eject hole ( ) and push firmly to release the tray.
  • Page 79 2.3.6 Keyboard Disassembly 1. Remove the battery pack. (Refer to section 2.3.1 Disassembly) 2. Remove four screws fastening the keyboard cover, then remove the keyboard cover. (figure 2-10) 3. Remove three screws fastening the keyboard. (Figure 2-11) Figure 2-10 Remove the keyboard cover Figure 2-11 Remove four screws...
  • Page 80 4. Slightly turn over the keyboard and disconnect the cable from the system board to detach the keyboard. (Figure 2-12) Figure 2-12 Remove the keyboard Reassembly 1. Reconnect the keyboard cable and fit the keyboard back into place, then secure the keyboard with three screws.. 2.
  • Page 81 2.3.7 LCD ASSY Disassembly 1. Remove the battery pack, CPU, DDR3, HDD, ODD and keyboard. (See sections 2.3.1~2.3.6 Disassembly) 2. Remove twenty-seven screws and disconnect one cable. (Figure 2-13) 3. Turn over the unit, remove nine screws and disconnect the touch pad cable, then remove the top cover. (Figure 2-14) Figure 2-13 Remove twenty-seven screws Figure 2-14 Remove the top cover and disconnect one cable...
  • Page 82 4. Remove nine screws and carefully pull the antenna wire and two cables out. Then free the LCD assembly. (Figure 2-15) Figure 2-15 Free the LCD assembly Reassembly 1. Attach the LCD assembly to the base unit and secure with nine screws. Reconnect the antenna wires and two cables. 2.
  • Page 83 2.3.8 Inverter Board Disassembly 1. Remove the LCD assembly. (Refer to section 2.3.7 Disassembly) 2. Remove six screws fastening the LCD cover. (Figure 2-16) 3. Insert a flat screwdriver to the lower part of the LCD cover and gently pry the frame out. Repeat the process as figure 1-20 arrowhead hints until the cover is completely separated from the housing.
  • Page 84 5. Disconnect two cables, then remove the inverter board. (Figure 2-18) Figure 2-18 Remove the inverter board Reassembly 1. Replace the inverter board and reconnect two cables. 2. Replace the LCD panel and inverter board into the LCD housing, then secure with nine screws. 3.
  • Page 85 2.3.9 LCD Panel Disassembly 1. Remove the LCD assembly and inverter board. (Refer to section 2.3.7 and 2.3.8 Disassembly) 2. Remove eight screws that secure the LCD brackets. (Figure 2-19) 3. Disconnect LCD cable to free the panel. (Figure 2-20) Figure 2-19 Remove eight screws Figure 2-20 Free the LCD panel Reassembly...
  • Page 86 2.3.10 Audio Jack Board Disassembly 1. Remove the LCD assembly. (Refer to sections 2.3.7 Disassembly) 2. Remove six screws fastening the shielding. Then remove the shielding. (Figure 2-21) 3. Remove one screw and disconnect two cables, then remove the audio jack board. (Figure 2-22) Figure 2-21 Remove the shielding Figure 2-22 Remove the audio jack board Reassembly...
  • Page 87 2.3.11 ODD Transfer Board Disassembly 1. Remove the LCD assembly. (Refer to sections 2.3.7 Disassembly) 2. Remove the shielding. (See step 2 of section 2.3.10 Disassembly) 3. Remove one screw fastening the ODD transfer board, the remove it flatly. (Figure 2-23) Figure 2-23 Remove the ODD transfer board Reassembly 1.
  • Page 88 2.3.12 System Board Disassembly 1. Remove the LCD assembly, audio jack board and ODD transfer board. (Refer to sections 2.3.7, 2.3.10&2.3.11 Disassembly) 2. Remove three screws fastening the system board. (Figure 2-24) 3. Remove two screws fastening the HDD cable and disconnect two cables, the free the system board. (Figure 2-25) Figure 2-24 Remove five screws Figure 2-25 Free the system board Reassembly...

  • Page 89: Mother Board

    3. Definition & Location of Major Components 3.1 Mother Board (Side A) -1 PJ701: Battery Connector PJ702: Power Jack Connector PJ701 J701 J701: External VGA Connector J704 J702: Mother Board to USB Board Connector PJ702 J702 J703 J703: RJ45 Connector J707 J708 J705...
  • Page 90 3. Definition & Location of Major Components 3.1 Mother Board (Side A) -2 U704: NVIDIA M96-PRO+ U705: Intel Arrandle CPU Socket U712: IBEX PEAK-M PM55 U705 U704 U712...

  • Page 91: Definition & Location Of Connectors/Switches

    3. Definition & Location of Connectors/Switches 3.1 Mother Board (Side B) J1: LCD Cable Connector J2: Internal Speaker Connector J3: Internal Keyboard Connector J4: Internal Touch-pad Connector J5: Bluetooth Board Connector J9: Audio Board Connector J10: Express Card Slot SW1: Power Button SW2: Touch-pad Left Button SW3: Touch-pad Right Button U16: KBC IT8502J...

  • Page 92: Pin Descriptions Of Ibex Peak-M

    4. Pin Descriptions of Ibex Peak-M 4.1 Digital Media Interface Signals Name Type Description DMI0TXP, Digital Media Interface Differential Transmit Pair 0 DMI0TXN DMI0RXP, Digital Media Interface Differential Receive Pair 0 DMI0RXN DMI0RXP, Digital Media Interface Differential Transmit Pair 1 DMI1RXN DMI0RXP, Digital Media Interface Differential Receive Pair 1...
  • Page 93 4.2 PCI Express* Signals –Table 1 Name Type Description PETp1, PCI Express* Differential Transmit Pair 1 PETn1 PERp1, PCI Express Differential Receive Pair 1 PERn1 PETp2, PCI Express Differential Transmit Pair 2 PETn2 PERp2, PCI Express Differential Receive Pair 2 PERn2 PETp3, PCI Express Differential Transmit Pair 3...
  • Page 94 4.2 PCI Express* Signals –Table 2 Name Type Description PETp5, PCI Express Differential Transmit Pair 5 PETn5 PERp5, PCI Express Differential Receive Pair 5 PERn5 PETp6, PCI Express Differential Transmit Pair 6 PETn6 PERp6, PCI Express Differential Receive Pair 6 PERn6 PERp6, PCI Express Differential Transmit Pair 7...
  • Page 95 4.3 Firmware Hub Interface Signals Name Type Description FWH[3:0] / Firmware Hub Signals. These signals are multiplexed with LAD[3:0] the LPC address signals. FWH4 / Firmware Hub Signals. This signal is multiplexed with the LFRAME# LPC LFRAME# signal. Initialization 3.3 V: INIT3_3V# is asserted by the Ibex Peak for 16 PCI clocks to reset the processor.
  • Page 96 4.4 PCI Interface Signals –Table 1 Name Type Description PCI Address/Data: AD[31:0] is a multiplexed address and data bus. During the first clock of a transaction, AD[31:0] contain a physical address (32 bits). During subsequent clocks, AD[31:0] AD[31:0] contain data. The Ibex Peakwill drive all 0s on AD[31:0] during the address phase of all PCI Special Cycles.
  • Page 97 4.4 PCI Interface Signals –Table 2 Name Type Description Device Select: The Ibex Peak asserts DEVSEL# to claim a PCI transaction. As an output, the Ibex Peak asserts DEVSEL# when a PCI master peripheral attempts an access to an internal Ibex Peak address or an address destined for DMI (main memory or graphics).
  • Page 98 4.4 PCI Interface Signals –Table 3 Name Type Description Initiator Ready: IRDY# indicates the Ibex Peak's ability, as an initiator, to complete the current data phase of the transaction. It is used in conjunction with TRDY#. A data phase is completed on any clock both IRDY# and TRDY# are sampled asserted.
  • Page 99 4.4 PCI Interface Signals –Table 4 Name Type Description Stop: STOP# indicates that the Ibex Peak, as a target, is requesting the initiator to stop the current transaction. STOP# causes the Ibex Peak, as an initiator, to stop the current STOP# transaction.
  • Page 100 4.4 PCI Interface Signals –Table 5 Name Type Description Parity Error: An external PCI device drives PERR# when it receives data that has a parity error. The Ibex Peak drives PERR# when it detects a parity error. The Ibex Peak can PERR# either generate an NMI# or SMI# upon detecting a parity error (either detected internally or reported via the PERR#...
  • Page 101 4.4 PCI Interface Signals –Table 6 Name Type Description PCI Reset: This is the Secondary PCI Bus reset signal. It is a logical OR of the primary interface PLTRST# signal and the PCIRST# state of the Secondary Bus Reset bit of the Bridge Control register (D30:F0:3Eh, bit 6).
  • Page 102 4.5 Serial ATA Interface Signals–Table 1 Name Type Description Serial ATA 0 Differential Transmit Pairs: These are outbound high-speed differential signals to Port 0. In SATA0TXP compatible mode, SATA Port 0 is the primary master of SATA SATA0TXN Controller 1. Serial ATA 0 Differential Receive Pair: These are inbound high-speed differential signals from Port 0.
  • Page 103 4.5 Serial ATA Interface Signals–Table 2 Name Type Description Serial ATA 2 Differential Receive Pair: These are inbound high-speed differential signals from Port 2. In compatible SATA2RXP mode, SATA Port 2 is the primary slave of SATA Controller 1 SATA2RXN NOTE: SATA Port 2 may not be available in all PCH SKUs.
  • Page 104 4.5 Serial ATA Interface Signals–Table 3 Name Type Description Serial ATA 5 Differential Transmit Pair: These are outbound SATA5TXP high-speed differential signals to Port 5. In compatible mode, SATA SATA5TXN Port 5 is the secondary master of SATA Controller 2 Serial ATA 5 Differential Receive Pair: These are inbound high- SATA5RXP speed differential signals from Port 5.
  • Page 105 4.5 Serial ATA Interface Signals–Table 4 Name Type Description Serial ATA 3 General Purpose: Same function as SATA0GP, except for SATA Port 3. If interlock switches are not required, this SATA3GP / pin can be configured as GPIO37. NOTE: This signal can also be GPIO37 used as GPIO37.
  • Page 106 4.6 LPC Interface Signals Name Type Description LPC Multiplexed Command, Address, Data: For LAD[3:0], LAD[3:0] / internal pull-ups are provided. FWH[3:0] LPC Frame: LFRAME# indicates the start of an LPC cycle, LFRAME# / or an abort. FWH4 LPC Serial DMA/Master Request Inputs: LDRQ[1:0]# are used to request DMA or bus master access.
  • Page 107 4.7 Interrupt Signals Name Type Description Serial Interrupt Request: This pin implements the serial I/OD SERIRQ interrupt protocol. PCI Interrupt Requests: In non-APIC mode the PIRQx# signals can be routed to interrupts 3, 4, 5, 6, 7, 9, 10, 11, 12, 14 or 15.
  • Page 108 4.8 USB Interface Signals –Table 1 Name Type Description Universal Serial Bus Port [1:0] Differential: These differential pairs are used to transmit Data/Address/Command signals for ports 0 and 1. These ports can be routed to UHCI USBP0P, controller #1 or the EHCI controller #1. USBP0N, NOTE: No external resistors are required on these signals.
  • Page 109 4.8 USB Interface Signals –Table 2 Name Type Description Universal Serial Bus Port [7:6] Differential: These differential pairs are used to transmit Data/Address/Command signals for ports 6 and 7. These ports can be routed to UHCI USBP6P, controller #4 or the EHCI controller #2. USBP6N, NOTE: No external resistors are required on these signals.
  • Page 110 4.8 USB Interface Signals –Table 3 Name Type Description Universal Serial Bus Port [13:12] Differential: These differential pairs are used to transmit Data/Address/Command signals for ports 13 and 12. These ports can be routed to UHCI USBP12P, controller #7 or the EHCI controller #2. USBP12N, NOTE: No external resistors are required on these signals.
  • Page 111 4.9 Power Management Interface Signals –Table 1 Name Type Description Platform Reset: The Ibex Peak asserts PLTRST# to reset devices on the platform (e.g., SIO, FWH, LAN, Processor, etc.). The Ibex Peak asserts PLTRST# during power-up and when S/W initiates a hard reset sequence through the Reset Control register (I/O Register CF9h).
  • Page 112 4.9 Power Management Interface Signals –Table 2 Name Type Description S5 Sleep Control: SLP_S5# is for power plane control. This signal is used to shut power off to all non-critical systems SLP_S5# / GPIO63 when in the S5 (Soft Off) states. Pin may also be used as GPIO63 Manageability Sleep State Control: This signal is used to control power planes to the Intel®...
  • Page 113 4.9 Power Management Interface Signals –Table 3 Name Type Description Power OK: When asserted, PWROK is an indication to the Ibex Peak that all of its core power rails have been stable for 10 ms. PWROK can be driven asynchronously. When PWROK is negated, the Ibex Peak asserts PLTRST#.
  • Page 114 4.9 Power Management Interface Signals –Table 4 Name Type Description System Reset: This pin forces an internal reset after being debounced. The Ibex Peak will reset immediately if the SMBus SYS_RESET# is idle; otherwise, it will wait up to 25 ms ± 2 ms for the SMBus to idle before forcing a reset on the system.
  • Page 115 4.9 Power Management Interface Signals –Table 5 Name Type Description PCI Express* Wake Event: Sideband wake signal on PCI WAKE# Express asserted by components requesting wake up. Suspend Status: This signal is asserted by the Ibex Peak to indicate that the system will be entering a low power state soon.
  • Page 116 4.9 Power Management Interface Signals –Table 6 Name Type Description Battery Low: Mobile only signal is an input from the battery BATLOW# to indicate that there is insufficient power to boot the system. (Mobile Only) / Assertion will prevent wake from S3–S5 state. This signal can GPIO72 also be enabled to cause an SMI# when asserted.
  • Page 117 4.10 Processor Interface Signals Name Type Description Keyboard Controller Reset CPU: The keyboard controller can generate INIT# to the processor. This saves the external OR gate with the PCH’s other sources of INIT#. When the PCH detects the assertion of this signal, INIT# is generated for RCIN# 16 PCI clocks.
  • Page 118 4.12 System Management Interface Signals Name Type Description Intruder Detect: This signal can be set to disable system if box detected open. This signal’s status is readable, so it can be INTRUDER# used like a GPI if the Intruder Detection is not needed. System Management Link 0 Data: SMBus link to external I/OD SML0DATA...
  • Page 119 4.13 Real Time Clock Interface Name Type Description Crystal Input 1: This signal is connected to the 32.768 kHz Special crystal. If no external crystal is used, then RTCX1 can be RTCX1 driven with the desired clock rate. Crystal Input 2: This signal is connected to the 32.768 kHz Special crystal.
  • Page 120 4.14 Miscellaneous Signals Name Type Description Internal Voltage Regulator Enable: This signal enables the internal 1.05 V regulators. INTVRMEN This signal must be always pulled-up to VccRTC. Speaker: The SPKR signal is the output of counter 2 and is internally “ANDed” with Port 61h bit 1 to provide Speaker Data Enable.
  • Page 121 4.15 Intel® High Definition Audio Link Signals –Table 1 Name Type Description Intel® High Definition Audio Reset: Master hardware reset HDA_RST# to external codec(s). Intel High Definition Audio Sync: 48 kHz fixed rate sample sync to the codec(s). Also used to encode the stream number. NOTE: This signal is sampled as a functional strap.
  • Page 122 4.15 Intel® High Definition Audio Link Signals –Table 2 Name Type Description High Definition Audio Dock Enable: This signal controls the external Intel HD Audio docking isolation logic. This is an active low signal. When deasserted the external docking switch is in isolate mode.
  • Page 123 4.16 Controller Link Signals Name Type Description CL_RST1# Controller Link Reset 1: Controller Link reset that connects (Mobile Only) / to a Wireless LAN Device supporting Intel® Active TP20 (Desktop Management Technology. Only) CL_CLK1 Controller Link Clock 1: bi-directional clock that connects to (Mobile Only) / a Wireless LAN Device supporting Intel®...
  • Page 124 4.18 Intel® Quiet System Technology Signals Name Type Description Fan Pulse Width Modulation Outputs: Pulse Width Modulated duty cycle output signal that is used for Intel® Quiet System Technology. PWM[3:0] When controlling a 3-wire fan, this signal controls a power (Desktop Only) OD O transistor that, in turn, controls power to the fan.
  • Page 125 4.19 JTAG Signals Name Type Description Test Clock Input (TCK): The test clock input provides the JTAG_TCK clock for the JTAG test logic. Test Mode Select (TMS): The signal is decoded by the Test JTAG_TMS Access Port (TAP) controller to control test operations. Test Data Input (TDI): Serial test instructions and data are JTAG_TDI received by the test logic at TDI.
  • Page 126 4.20 Dual Channel NAND Interface –Table 1 Name Type Description Data Input/Output: The bidirectional I/O used to transfer command, address and data to and from NAND device. Data is output during write operations and input during read NV_DQ[15:0] / NV_IO[15:0] operations.
  • Page 127 4.20 Dual Channel NAND Interface –Table 2 Name Type Description Source Synchronous Mode: Write Read[1:0]# Indicates owner of the NV_DQ / NV_IO and NV_DQS signals. ‘1’, NV_DQ / NV_IO and NV_DQS are driven by IBX NAND Controller. NV_WR#[1:0] ‘0’, NV_DQ / NV_IO and NV_DQS are driven by the NAND /NV_RE#[1:0] device.
  • Page 128 4.21 Clock Interface Signals –Table 1 Name Type Description 133 MHz differential reference clock from a clock chip in CLKIN_BCLK_P, Buffer-Through Mode. Unused when Integrated Clock CLKIN_BCLK_N Generation is enabled. CLKOUT_BCLK0_P 133MHz Differential output to Processor or 100 MHz PCIe* Gen 1.1 specification differential output to PCI Express CLKOUT_PCIE8_P, devices.
  • Page 129 4.21 Clock Interface Signals –Table 2 Name Type Description CLKIN_DOT96P, 96MHz differential reference clock from a clock chip. CLKIN_DOT96N Connection for 25MHz crystal to Ibex Peak oscillator circuit. XTAL25_IN Connection for 25MHz crystal to Ibex Peak oscillator circuit. XTAL25_OUT Single-ended 14.31818MHz reference clock driven by a clock REFCLK14IN chip.
  • Page 130 4.21 Clock Interface Signals –Table 3 Name Type Description PCIECLKRQ0# / GPIO73, PCIECLKRQ1# / GPIO18, PCIECLKRQ2# / GPIO20, Clock Request Signals for PCI Express 100 MHz Clocks Can PCIECLKRQ3# / instead by used as GPIOs GPIO25, PCIECLKRQ4# / NOTE: External Pull-up Resistor required if used for GPIO26, CLKREQ# functionality PCIECLKRQ5# /...
  • Page 131 4.21 Clock Interface Signals –Table 4 Name Type Description Configurable as a GPIO or as an Intel Management Firmware programmable output clock which can be configured as one of the following: CLKOUTFLEX0 / -33 MHz GPIO64 -14.31818 MHz -DC Output logic ‘0’ - (Default) NOTE: Default clock setting requires no ME FW configuration.
  • Page 132 4.22 LVDS Interface Signals –Table 1 Name Type Description LVDSA_DATA LVDS Channel A differential data output - positive [3:0] LVDSA_DATA LVDS Channel A differential data output -negative #[3:0] LVDS Channel A differential clock output - positive LVDSA_CLK LVDS Channel A differential clock output - negative LVDSA_CLK# LVDSB_DATA LVDS Channel B differential data output - positive...
  • Page 133 4.22 LVDS Interface Signals –Table 2 Name Type Description EDID support for flat panel display L_DDC_DATA Control signal (clock) for external SSC clock chip control – L_CTRL_CLK optional Control signal (data) for external SSC clock chip control – L_CTRL_DAT optional LVDS Panel Power Enable: Panel power control enable control for LVDS.
  • Page 134 4.23 Analog Display Interface Signals Name Type Description RED Analog Video Output: This signal is a CRT Analog CRT_RED video output from the internal color palette DAC. GREEN Analog Video Output: This signal is a CRT Analog CRT_GREEN video output from the internal color palette DAC. BLUE Analog Video Output: This signal is a CRT Analog CRT_BLUE video output from the internal color palette DAC.
  • Page 135 4.24 Intel Flexible Display Interface Signals Name Type Description Display Link 1 positive data in FDI_RXP[3:0] Display Link 1 negative data in FDI_RXN[3:0] Display link 1 Frame sync FDI_FSYNC[0] Display link 1 Line sync FDI_LSYNC[0] Display Link 2 positive data in FDI_RXP[7:4] Display Link 2 negative data in FDI_RXN[7:4]...
  • Page 136 4.26 Digital Display Interface Signals –Table 1 Name Type Description Port B: Capable of SDVO / HDMI / DVI / DisplayPort SDVO DDPB_[0]P: red DDPB_[1]P: green DDPB_[2]P: blue DDPB_[3]P: clock HDMI / DVI Port B Data and Clock Lines DDPB_[0]P: TMDSB_DATA2 DDPB_[3:0]P DDPB_[1]P: TMDSB_DATA1 DDPB_[2]P: TMDSB_DATA0...
  • Page 137 4.26 Digital Display Interface Signals –Table 2 Name Type Description Port B: Capable of SDVO / HDMI / DVI / DisplayPort SDVO DDPB_[0]N: red complement DDPB_[1]N: green complement DDPB_[2]N: blue complement DDPB_[3]N: clock complement HDMI / DVI Port B Data and Clock Line Complements DDPB_[0]N: TMDSB_DATA2B DDPB_[3:0]N DDPB_[1]N: TMDSB_DATA1B...
  • Page 138 4.26 Digital Display Interface Signals –Table 3 Name Type Description SDVO_INTP: Serial Digital Video Input Interrupt SDVO_INTP SDVO_INTN: Serial Digital Video Input Interrupt SDVO_INTN Complement. SDVO_TVCLKINP: Serial Digital Video TVOUT SDVO_TVCLK Synchronization Clock. SDVO_TVCLKINN: Serial Digital Video TVOUT SDVO_TVCLK Synchronization Clock Complement. SDVO_STALL SDVO_STALLP: Serial Digital Video Field Stall.
  • Page 139 4.26 Digital Display Interface Signals –Table 4 Name Type Description Port C: Capable of HDMI / DVI / DisplayPort HDMI / DVI Port C Data and Clock Line Complements DDPC_[0]N: TMDSC_DATA2B DDPC_[1]N: TMDSC_DATA1B DDPC_[2]N: TMDSC_DATA0B DDPC_[3]N: TMDSC_CLKB DDPC_[3:0]N DisplayPort Port C Complements DDPC_[0]N: Lane 0 complement DDPC_[1]N: Lane 1 complement DDPC_[2]N: Lane 2 complement...
  • Page 140 4.26 Digital Display Interface Signals –Table 5 Name Type Description Port D: Capable of HDMI / DVI / DP HDMI / DVI Port D Data and Clock Lines DDPD_[0]P: TMDSC_DATA2 DDPD_[1]P: TMDSC_DATA1 DDPD_[2]P: TMDSC_DATA0 DDPD_[3]P: TMDSC_CLK DDPD_[3:0]P DisplayPort Port D DDPD_[0]P: Display Port Lane 0 DDPD_[1]P: Display Port Lane 1 DDPD_[2]P: Display Port Lane 2...
  • Page 141 4.27 General Purpose I/O Signals –Table 1 Note: 1. GPIO Configuration registers within the Core Well are reset whenever PWROK is deasserted. 2. GPIO Configuration registers within the Suspend Well are reset when RSMRST# is asserted, CF9h reset (06h or 0Eh) event occurs, or SYS_RST# is asserted. 3.
  • Page 142 4.27 General Purpose I/O Signals –Table 2 Power Blink Name Type Tolerance Default Description Well Capability GPIO59 3.3 V Suspend Native Multiplexed with OC[0]# (Note 12) GPIO58 3.3 V Suspend Native Multiplexed with SML1CLK GPIO57 3.3 V Suspend Unmultiplexed GPIO56 3.3 V Suspend Native...
  • Page 143 4.27 General Purpose I/O Signals –Table 3 Power Blink Name Type Tolerance Default Description Well Capability GPIO35 3.3 V Core Unmultiplexed. GPIO34 3.3 V Core Multiplexed with STP_PCI# Multiplexed with HDA_DOCK_EN# GPIO33 3.3 V Core (Mobile Only) (Note 4) GPO, Unmultiplexed (Desktop Only) Native GPIO32...
  • Page 144 4.27 General Purpose I/O Signals –Table 4 Power Blink Name Type Tolerance Default Description Well Capability GPIO20 3.3 V Core Native Multiplexed with PCIECLKRQ2# GPIO19 3.3 V Core Multiplexed with SATA1GP GPIO18 3.3 V Core Native Yes (Note 6) Multiplexed with PCIECLKRQ1# Multiplexed with TACH0.
  • Page 145 4.27 General Purpose I/O Signals NOTES: All GPIOs can be configured as either input or output. GPI[15:0] can be configured to cause a SMI# or SCI. Note that a GPI can be routed to either an SMI# or an SCI, but not both. Some GPIOs exist in the VccSus3_3 power plane.
  • Page 146 4.27 General Purpose I/O Signals NOTES: For GPIOs where GPIO vs. Native Mode is configured via SPI Soft Strap, the corresponding GPIO_USE_SEL bits for these GPIOs have no effect. The GPIO_USE_SEL bits for these GPIOs may change to reflect the Soft-Strap configuration even though GPIO Lockdown Enable (GLE) bit is set.
  • Page 147 4.28 Manageability Signals -1 The following signals can be optionally utilized by Ibex Peak Management engine supported applications and appropriately configured by Management Engine firmware. When configured and utilized as a Manageability function, the associated host GPIO functionality is no longer available.
  • Page 148 4.28 Manageability Signals -2 Name Type Description Used as an alert (active low) to indicate to the external SATA5GP / GPIO49 / controller (e.g EC or SIO) that temperatures are out of range for the PCH or Graphics/Memory Controller or the Processor TEMP_ALERT# Core.
  • Page 149 4.29 Power and Ground Signals –Table 1 Name Description Decoupling: This signal is for RTC decoupling only. This DcpRTC signal requires decoupling. Decoupling: Internally generated 1.5V powered off of Suspend Well. This signal requires decoupling. Decoupling is DcpSST required even if this feature is not used. Decoupling: 1.05 V Suspend well supply that is supplied DcpSus internally by Internal VRs.
  • Page 150 4.29 Power and Ground Signals –Table 1 Name Description Decoupling: This signal is for RTC decoupling only. This DcpRTC signal requires decoupling. Decoupling: Internally generated 1.5V powered off of Suspend Well. This signal requires decoupling. Decoupling is DcpSST required even if this feature is not used. Decoupling: 1.05 V Suspend well supply that is supplied DcpSus internally by Internal VRs.
  • Page 151 4.29 Power and Ground Signals –Table 2 Name Description Power supply for DMI. 1.1 V or 1.05 V based on the processor used. Please refer to the VccDMI respective processor documentation to find the appropriate voltage level. 1.05 V supply for LAN controller logic. This is a separate power plane that may or may not be powered in S3–S5 states.
  • Page 152 4.29 Power and Ground Signals –Table 3 Name Description 1.05 V supply for Display PLL A Analog Power. This power is VccADPLLA supplied by the core well. 1.05 V supply for Display PLL B Analog Power. This power is VccADPLLB supplied by the core well.
  • Page 153 4.29 Power and Ground Signals –Table 4 Name Description Non-Critical To Function. These pins are for package mechanical reliability. TP22_NCTF Note: These pins should be connected to Ground. 1.05 V Analog power supply for internal clock PLL. This requires a filter and power is supplied by the core well. VccAClk NOTE: This pin can be left as no connect in On-Die VR enabled mode (default).
  • Page 154 4.30 Functional Strap Definitions –Table 1 The following signals are used for static configuration. They are sampled at the rising edge of PWROK to select configurations (except as noted), and then revert later to their normal usage. To invoke the associated mode, the signal should be driven at least four PCI clocks prior to the time it is sampled.
  • Page 155 4.30 Functional Strap Definitions –Table 2 The following signals are used for static configuration. They are sampled at the rising edge of PWROK to select configurations (except as noted), and then revert later to their normal usage. To invoke the associated mode, the signal should be driven at least four PCI clocks prior to the time it is sampled.
  • Page 156 4.30 Functional Strap Definitions –Table 3 When Name Usage Comment Sampled The signal has a weak internal pull-up. Note: the internal pull-up is disabled after PCIRST# de- asserts. If the signal is sampled low, this indicates that the system is Top-Block Swap Rising edge of strapped to the “topblock swap”...
  • Page 157 4.30 Functional Strap Definitions –Table 4 When Name Usage Comment Sampled This Signal has a weak internal pull-up. Note: the internal pull-up is disabled after PCIRST# de- asserts. This field determines the destination of accesses to the BIOS memory range. Also controllable via Boot BIOS Destination bit (Chipset Config Registers:Offset 3410h:bit 11).
  • Page 158 4.30 Functional Strap Definitions –Table 5 When Name Usage Comment Sampled This Signal has a weak internal pull-up. Note: the internal pull-up is disabled after PCIRST# de-asserts. This field determines the destination of accesses to the BIOS memory range. Also controllable via Boot BIOS Destination bit (Chipset Config Registers:Offset 3410h:bit 10).
  • Page 159 4.30 Functional Strap Definitions –Table 6 When Name Usage Comment Sampled This Signal has a weak internal pull-up. Note: the internal pull-up is disabled after PCIRST# de-asserts. This field determines the destination of accesses to the BIOS memory range. Also controllable via Boot BIOS Destination bit (Chipset Config Registers:Offset 3410h:bit 10).
  • Page 160 4.30 Functional Strap Definitions –Table 7 When Name Usage Comment Sampled This Signal has a weak internal pull-up. Note: the internal pull-up is disabled after ESI Strap Rising edge of PCIRST# de-asserts.Tying this strap low configures DMI for GNT2#/ (Server Only) PWROK ESI compatible operation.
  • Page 161 4.30 Functional Strap Definitions –Table 8 When Name Usage Comment Sampled Rising edge of This signal has a weak internal pull-down resistor. This signal Functionality SPI_MOSI MEPWROK must be sampled low. Disable Rising edge of Termination This signal has a weak internal pull-down. NV_CLE PWROK Voltage...

  • Page 162: System Block Diagram

    5. System Block Diagram U705 U704 PCIEx16 DDR3 1066MHZ PROCESSOR Nvida ARRANDALE M96-PRO+ HDMI DMI2 SATA SATA ODD INT MIC SATA SATA HDD EXT MIC Azalia AUDIO SATA ESATA/USB CODEC LINE OUT/SPIDF COBO U712 ALC663 Headphone WEBCAM L-speaker X10 Receiver APA2031 R-speaker IBEX PEAK-M...

  • Page 163: Trouble Shooting

    6. Trouble Shooting 6.1 No Power (*1) 6.2 No Display (*2) 6.3 Graphics Controller Failure LCD No Display 6.4 External Monitor No Display 6.5 Memory Failure 6.6 Keyboard (K/B) or Touch-Pad (T/P) Failure 6.7 Hard Disk Drive Failure 6.8 ODD Failure 6.9 USB Ports Failure 6.10 Audio Failure 6.11 LAN Failure...
  • Page 164 *1: No Power Definition Base on ACPI Spec. We define the no power as while we press the power button, the system can’t leave S5 status or none the PG signal send out from power supply. Judge condition: Check whether there are any voltage feedback control to turn off the power. Check whether no CPU power will cause system can’t leave S5 status.

  • Page 165: No Power

    6.1 No Power When the power button is pressed, nothing happens, no fan activity is heard and power indicator is not light up. Check following parts and signals: No Power Parts: Signals: PJ702 1908_CSSN Board-level PF702 1908_CSSP Is the Troubleshooting EL709 notebook connected ADINP...

  • Page 166: No Display

    6.2 No Display There is no display on both LCD and VGA monitor after power on although the LCD and monitor is known-good. Refer to port error code No Display description section to find out which part is causing System Monitor the problem.

  • Page 167: Graphics Controller Failure Lcd No Display

    6.3 Graphics Controller Failure LCD No Display There is no display or picture abnormal on LCD although power-on-self-test is passed. Graphics Controller Failure LCD No Display Check if 1. Confirm LCD panel or monitor is good Re-soldering. J1 are cold and check the cable are connected solder? properly.

  • Page 168: External Monitor No Display

    6.4 External Monitor No Display There is no display or picture abnormal on CRT monitor, but it is OK for LCD. External Monitor No Display 1. Confirm monitor is good and check Check if J701 Board-level Re-soldering. the cable are connected properly. is cold solder? Troubleshooting 2.

  • Page 169: Memory Failure

    6.5 Memory Failure Extend DDR2 SO-DIMM is failure or system hangs up. Memory Failure One of the following components or signals on the motherboard 1. Check the extend SO-DIMM module is may be defective ,Use an oscilloscope to check the signals or installed properly.

  • Page 170: Keyboard (K/B) Or Touch-Pad (T/P) Failure

    6.6 Keyboard (K/B) or Touch-Pad (T/P) Failure Error message of keyboard or touch-pad test error is shown or any key does not work. Keyboard (K/B) or Touch-Pad (T/P) Failure Check J3, J4 Re-soldering. Board-level for cold solder? Troubleshooting Is K/B or T/P cable connected to notebook Correct it.

  • Page 171: Hard Disk Drive Failure

    6.7 Hard Disk Drive Failure Either an error message is shown, or the drive motor spins non-stop, while reading data from or writing data to hard disk. Hard Disk Drive Failure 1. Check if BIOS setup is OK?. Board-level 2. Try another working drive. Troubleshooting One of the following parts or signals on the motherboard may be defective, use an oscilloscope to check the signals or replace...

  • Page 172: Odd Failure

    6.8 ODD Failure An error message is shown when reading data from ODD drive. ODD Failure Board-level 1. Try another known good compact disk. Troubleshooting 2. Check install for correctly. One of the following parts or signals on the motherboard may be defective, use an oscilloscope to check the signals or replace the parts one at a time and test after each replacement.

  • Page 173: Usb Ports Failure

    6.9 USB Ports Failure An error occurs when a USB I/O device is installed. USB Ports Failure Check if the USB device is installed properly. Board-level Check the following parts for cold solder or one of the following parts on the mother-board may be defective, use an oscilloscope Troubleshooting to check the following signal or replace the parts one at a time Test...

  • Page 174: Audio Failure

    6.10 Audio Failure No sound from speaker after audio driver is installed. Audio Failure 1. Check if speaker cables are connected properly. 2. Make sure all the drivers are Board-level Check the following parts for cold solder or one of the following parts on the installed properly.

  • Page 175: Lan Failure

    6.11 LAN Failure An error occurs when a LAN device is installed. LAN Failure Check the following parts for cold solder or one of the following 1.Check if the driver is installed properly. parts on the mother-board may be defective, use an oscilloscope 2.Check if the notebook connect with the to check the following signal or replace the parts one at a time and LAN properly.

  • Page 176: Card Reader Slot Failure

    6.12 Card Reader Slot Failure An error occurs when a card device is installed. Card Reader Slot Failure Check the following parts for cold solder or one of the following 1. Check if the card device is Board-level parts on the mother-board may be defective, use an oscilloscope installed properly.

  • Page 177: Mini Express (Wireless) Socket Failure

    6.13 Mini Express (Wireless) Socket Failure An error occurs when a wireless card device is installed. Mini Express (Wireless) Socket Failure Board-level Troubleshooting 1. Check if the wireless card device is installed properly. 2. Confirm wireless driver is installed ok. Check the following parts for cold solder or one of the following parts on the mother-board may be defective, use an oscilloscope to check the following signal or replace the parts one at a time and...

  • Page 178: Express Card Socket Failure

    6.14 Express Card Socket Failure An error occurs when a express card device is installed. Express Card Socket Failure Board-level Troubleshooting 1. Check if the express card device is installed properly. 2. Confirm express card driver is installed ok. Check the following parts for cold solder or one of the following parts on the mother-board may be defective, use an oscilloscope to check the following signal or replace the parts one at a time and test after each replacement.

  • Page 179: Reference Material

    70D N/B Maintenance 70D N/B Maintenance Reference Material Intel Arrandale Processor Intel, INC Intel Ibex Peak chipset Intel, INC ATI M96-PRO+ VGA Controller AMD, INC Keyboard controller IT8502J WIN, INC Hardware Engineering Specification Technology Corp/MITAC...
  • Page 180 70D N/B Maintenance 70D N/B Maintenance SERVICE MANUAL FOR 9270D SERVICE MANUAL FOR Sponsoring Editor : Miny.Feng Author : Wenrong.Pu Publisher : MiTAC Technology Corp. Address : No.269, Road 2, Export Processing Zone, Kunshan, P.R.C Tel : 086-512-57367777 Fax : 086-512-57385099 First Edition : Jan.
