  • Page 1 User’s Manual (November 2007)
  • Page 2 TRADEMARKS ® The Bluetooth word mark and logos are registered trademarks owned by Bluetooth SIG, Inc. All other brand and product names are trademarks or registered trademarks of their respective owners. NOTE The information in this manual is subject to change without notice.
  • Page 3 ® ENERGY STAR is a government program that offers businesses and consumers energy-efficient solutions, making it easy to save money while protecting the environment for future generations. Please reference ENERGY STAR www.energystar.gov. As an ENERGY STAR® Partner, MiTAC Technology Corporation has determined that this product meets the ENERGY STAR energy efficiency.
  • Page 4 Over its lifetime, ENERGY STAR home office (e.g., computer, monitor, printer, and fax) can save enough electricity to light an entire home for more than 4 years. Power management (“sleep settings”) on computers and monitors can result in much savings annually. Remember, saving energy prevents pollution Because most computer equipment is left on 24 hours a day, power management features are important for saving energy and are an easy way...

  • Page 5: Table Of Contents

    Table of Contents Preface ... vi Chapter 1 Getting Started...1-1 Getting the Computer Running ... 1-2 Unpacking ... 1-2 Connecting to AC Power ... 1-2 Opening the Cover ... 1-4 Turning On and Off the Computer... 1-4 Taking a Look at the Computer... 1-6 Right-Side Components ...
  • Page 6 Hot Keys ... 2-8 Using the Touchpad ... 2-11 Configuring the Touchpad ... 2-13 Using the Touchscreen (Optional) ... 2-14 Using the Hard Disk Drive... 2-16 Installing a Second Hard Disk Drive (Optional) ... 2-16 Using the Optical Drive (Optional) ... 2-18 Inserting and Removing a Disc ...
  • Page 7 Chapter 4 Expanding Your Computer ...4-1 Connecting an External Monitor ... 4-2 Connecting a Serial Device ... 4-4 Connecting a USB Device... 4-5 Connecting an IEEE 1394 Device... 4-6 Using Smart Cards (Optional)... 4-7 Inserting and Removing a Smart Card ... 4-7 Using PC Cards ...
  • Page 8 Chapter 7 Caring for the Computer ...7-1 Protecting the Computer... 7-2 Using the Windows Security Center ... 7-2 Using the Cable Lock... 7-3 Taking Care of the Computer... 7-4 Location Guidelines ... 7-4 General Guidelines... 7-4 Cleaning Guidelines ... 7-5 Battery Pack Guidelines ...
  • Page 9 Appendix A Specifications ... A-1 Appendix B Regulatory Information ... B-1 On the Use of the System ...B-2 Class B Regulations ...B-2 Safety Notices ...B-3 On the Use of the RF Device...B-6 USA and Canada Safety Requirements and Notices...B-6 European Union CE Marking and Compliance Notices ..B-9...

  • Page 10: Preface

    Preface This manual contains information that will help you operate the computer. It is divided into 8 chapters and 2 appendices. Chapter 1, Getting Started, takes you through the process of setting up the computer and identifying its external components. Chapter 2, Operating Your Computer, tells you how to use the computer’s components and features.

  • Page 11: Notational Conventions

    Notational Conventions Throughout this manual, the following conventions are used to distinguish elements of text. NOTE: identifies additional information that requires special attention. CAUTION: identifies important information that, if not followed, may result in loss of data or damage to the computer. Keyboard keys are shown in a bold typeset.

  • Page 12: Getting Started

    Getting Started Congratulations on purchasing this rugged computer. This chapter first tells you step by step how to get the computer up and running. You will find instructions for these procedures: Unpacking Connecting to AC power Opening and closing the cover Turning on the computer Turning off the computer Then, you will find a section briefly introducing the external components...

  • Page 13: Getting The Computer Running

    Getting the Computer Running This section guides you through the procedures for getting the computer ready for operation. Unpacking After unpacking the shipping carton, you should find these standard items: Rugged computer Accessories: − AC adapter − AC power cord −...
  • Page 14 3. Plug the female end of the AC power cord to the AC adapter and the male end to an electrical outlet ( ). 4. Power is being supplied from the electrical outlet to the AC adapter and onto your computer. Now, you are ready to turn on the computer. 5.

  • Page 15: Opening The Cover

    Opening the Cover CAUTION: Be gentle when opening and closing the cover. Opening it vigorously or slamming it shut could damage the computer. Open the top cover by pushing on the cover latch ( ) and lifting up the cover ( ). You can tilt the cover forward or backward for optimal viewing clarity.
  • Page 16 2. Press the power button ( 3. Each time the computer is turned on, it performs a Power-On Self Test (POST), and the Windows operating system should start. Turning Off To turn off the computer power, use the “Shut Down” command of your operating system.

  • Page 17: Taking A Look At The Computer

    Taking a Look at the Computer This section identifies the external components of the computer and briefly describes the function of each component. NOTE: Depending on the model you purchased, the appearance of your computer may not be exactly the same as those shown in this manual. Right-Side Components NOTE: You may need to open the covers to be able to see the right-side components.
  • Page 18 Component Connects an IEEE 1394 device such as a Mini IEEE 1394 scanner, printer, DVCAM, VCR, and more. Port Serves as the master control that turns the RF (radio frequency) On/Off wireless LAN radio, Bluetooth radio, and WWAN on/off. Switch Accepts a MultiMediaCard (MMC), Secure Card Reader Digital (SD), Memory Stick (MS) or Memory...

  • Page 19: Left-Side Components

    Left-Side Components NOTE: You may need to open the covers to be able to see the left-side components. Component Supplies power to your computer when Battery Pack external power is not connected. Depending on your model, the media bay may Media Bay contain any of the following: Accepts a compact disc for installing or...

  • Page 20: Rear Components

    Rear Components NOTE: You may need to open the covers to be able to see the rear components. Component Power Connector Connects the AC adapter. Connects a USB device, such as a USB flash USB Port disk, printer, digital camera, joystick, and more.

  • Page 21: Front Components

    Front Components Component Top Cover Latch Locks the top cover. Provides a convenient way to carry the Handle computer anywhere. Getting Started Description See Also P. 1-4 1-10...

  • Page 22: Bottom Components

    Bottom Components Component Inside are the memory slots for expanding Memory Slots the memory size of your computer. Getting Started Description See Also P. 4-16 1-11...

  • Page 23: Top-Open Components

    Top-open Components Component Displays the output of the computer. May LCD Screen include the optional touchscreen feature. Getting Started Description See Also P. 2-21 1-12...
  • Page 24 Component Quick Buttons Turns off/on the LCD display and LED indicators, or User customized program quick launch key. NOTE: The function of P1 quick button depends on your setting in BIOS Setup program under the Advanced menu (see chapter 5 for details). Enables/disables power saving when using battery power.
  • Page 25 Component Receives sound and voice for the computer. Microphone Serves as the data input device of the Keyboard computer. Serves as the fingerprint verification, Fingerprint preventing unauthorized access to your Sensor computer. Sends out sound and voice from the computer. Stereo Speaker Show the current status of the computer’s Indicators...
  • Page 26 IMPORTANT: To ensure the waterproof integrity, close the connector covers completely. When closing the covers, push the four corners and make sure that the cover fits in completely. Getting Started 1-15...

  • Page 27: Where To Go From Here

    Where to Go from Here As your computer is ready for operation, you may want to do any of the following now: For this purpose... To know more about the computer... To install the operating system if your dealer has not already done so... To know more about the operating system...

  • Page 28: Operating Your Computer

    Operating Your Computer This chapter provides information about the use of the computer. If you are new to computers, reading this chapter will help you learn the operating basics. If you are already a computer user but are new to rugged computers, you may choose to read only the parts containing information unique to your computer.

  • Page 29: Starting And Stopping The Computer

    Starting and Stopping the Computer There are a number of ways to start and stop the computer. Starting the Computer You always start the computer using the power button ( ). A computer starts up with an operating system (OS) existing on the storage device such as the hard disk.
  • Page 30 To stop in this mode... Hibernation Depending on your settings in Windows, you can place the computer in Hibernation mode by: • Closing the display cover • Pressing the power button If you choose to stop in Sleep or Hibernation mode, you can return to where you left off the next time you start up the computer.

  • Page 31: Using The Quick Buttons

    Using the Quick Buttons Located on top of the keyboard are four quick buttons: LCD display and LED indicators quick button (P1) to turn off the LCD display and LED indicator, or User customized program quick launch key (P1) – see chapter 6 for more details.
  • Page 32 Light sensor quick button ( ) for adjusting the LCD brightness automatically based on your computer’s surrounding lighting condition. Lights green when light sensor is enabled. Operating Your Computer...

  • Page 33: Using The Internal Keyboard

    Using the Internal Keyboard Your keyboard has all the standard functions of a full-sized computer keyboard plus a key added for specific functions. The standard functions of the keyboard can be further divided into four major categories: Typewriter keys Cursor-control keys Numeric keys Function keys Typewriter Keys...

  • Page 34: Cursor-Control Keys

    Cursor-Control Keys NOTE: The word “cursor” refers to the indicator on the screen that lets you know exactly where on your screen anything you type will appear. It can take the form of a vertical or horizontal line, a block, or one of many other shapes. Numeric Keypad A 15-key numeric keypad is embedded in the typewriter keys as shown next:...

  • Page 35: Function Keys

    Numeric keys facilitate entering of numbers and calculations. When Num Lock is on, the numeric keys are activated; meaning you can use these keys to enter numerals. NOTE: When the numeric keypad is activated and you need to type the English letter in the keypad area, you can turn Num Lock off or you can press Fn and then the letter without turning Num Lock off.
  • Page 36 Description Switches the wireless LAN radio on and off. Switches the night vision feature on and off for viewing the display when using night vision goggles (optional). Decreases the sound volume. Increases the sound volume. Switches the display output to one of the following when external devices are connected.

  • Page 37: Euro Symbol

    Serves as the sleep button that you can define with Windows’ Power Options. (See the “Power Management” in Chapter 3.) Switches the keyboard backlight on and off (option). Euro Symbol You can press the euro dollar sign To press the euro sign on a United States-International keyboard, hold down the key and press Alt Gr...

  • Page 38: Using The Touchpad

    Using the Touchpad CAUTION: Do not use a sharp object such as a pen on the touchpad. Doing so may damage the touchpad surface. NOTE: Press Fn+F9 to toggle the touchpad on or off. For optimal performance of the touchpad, keep your fingers and the pads clean and dry.
  • Page 39 Here are some common terms that you should know when using the touchpad: Term Point Move your finger on the pad until the cursor points to the selection on the screen. Click Press and release the left button. –or– Tap gently anywhere on the pad. Double-click Press and release the left button twice in quick succession.

  • Page 40: Configuring The Touchpad

    Configuring the Touchpad You may want to configure the touchpad to suit your needs. For example, if you are a left-handed user, you can swap the two buttons so that you can use the right button as the left button and vice versa. You can also change the size of the on-screen pointer, the speed of the pointer, and so on.

  • Page 41: Using The Touchscreen (Optional)

    Using the Touchscreen (Optional) NOTE: Make sure the touchscreen driver has been installed properly. Press Fn+F8 to toggle the touchscreen on or off. CAUTION: Do not use a sharp object such as a ballpoint pen or pencil on the touchscreen. Doing so may damage the touchscreen surface. Use your finger or the included touchscreen pen (option).
  • Page 42 Here are some common terms that you should know when using the touchscreen: Term Click/Point Tap gently on the touchscreen. Double-click Tap twice on the touchscreen rapidly. Drag and Press lightly on the touchscreen and move your finger/ drop touchsreen pen until you reach your destination (drag). Finally, release your finger/touchscreen pen (drop) when you finish dragging your selection to the destination.

  • Page 43: Using The Hard Disk Drive

    Using the Hard Disk Drive Your computer comes with a removable hard disk drive as drive C. A hard disk drive is a storage device with non-removable, rotating, magnetic storage platters inside it. It is where your operating system and application software programs are stored.
  • Page 44 4. Be careful to observe the correct orientation and slide the hard disk drive bracket into the media bay until it reaches the end. 5. Close the media bay cover to secure the hard disk drive bracket. NOTE: To remove the second hard disk drive, press upward the hard drive release latch ( ) and carefully pull on the ribbon strip ( ) to remove the hard drive.

  • Page 45: Using The Optical Drive (Optional)

    Using the Optical Drive (Optional) Your computer may come with an optical drive, usually configured as drive D. Depending on the model, your drive is one of the following: Combo drive can work both as a DVD drive (reading DVD discs in addition to CDs, audio CDs and CD-R/-RW discs), and also as a CD recorder (writing to CD-R/-RW discs).

  • Page 46: Inserting And Removing A Disc

    Inserting and Removing a Disc Follow this procedure to insert or remove a disc: 1. Turn on the computer. 2. Open the media bay cover by sliding the release latch towards the left. 3. Press the eject button and the DVD tray will slide out partially. Gently pull on it until it is fully extended.
  • Page 47 6. Close the media bay cover. NOTE: In the unlikely event that you are unable to release the drive tray by pressing the eject button, you can manually release the disc. (See “Optical Drive Problems” in Chapter 8.) Operating Your Computer 2-20...

  • Page 48: Using The Video Features

    Using the Video Features The video subsystem of your computer features: 13.3-inch wide TFT (Thin-Film Transistor) color LCD display with 1024×768 XGA resolution Multi-display capability, which allows you to expand your desktop on the screen to another display device so that you have more desktop space to work on Sunlight-readable LCD display by pressing sunlight readable quick button (...

  • Page 49: Using The Audio Features

    Using the Audio Features NOTE: If you experience interference while recording, try lowering the microphone recording volume. The audio subsystem of your computer features: Azalia interface (high density audio codec) 2-channel analog output Built-in microphone ( ) External audio connectors ( ) and Set of speakers ( ) Ways of playing and recording sound vary with the operating system used.

  • Page 50: Connecting Audio Devices

    Connecting Audio Devices For higher audio quality, you can send or receive sound through external audio devices. NOTE: After connecting an external audio device, make sure that you specify the use of the correct audio device in Windows. Audio Output Connector (green) can be connected to speakers, headphones, or earphone set.

  • Page 51: Using The Communication Features

    Using the Communication Features Using the Modem The internal 56 K fax/data modem allows you to use the telephone line to communicate with others by fax, email, or connect to an online service or bulletin board. To connect the telephone line to the modem, connect one end of the modem cable to the RJ-11 connector on the computer and the other end to the phone line.

  • Page 52: Using The Lan

    Using the LAN The internal 10/100/1000Base-T LAN (Local Area Network) module allows you to connect your computer to a network. It supports data transfer rate up to 1000 Mbps. To connect the network cable to the LAN module, connect one end of the LAN cable to the RJ-45 connector on the computer and the other end to the network hub.

  • Page 53: Using The Wireless Lan

    Using the Wireless LAN Depending on your model, an internal mini PCI-E wireless LAN (WLAN) card may have been pre-installed by your computer manufacturer at the factory. This card allows you to access corporate networks or the Internet in a wireless environment. The WLAN features include: Peer-to-Peer (Ad-Hoc) and Access Point (Infrastructure) modes support...

  • Page 54: Connecting To A Wireless Network

    Turning Off/On the WLAN Radio NOTE: The FAA (Federal Aviation Agency) has deemed it unsafe to operate wireless devices in aircraft as this may interfere with flight safety. Remember to turn off wireless LAN when using your computer in the airplane. To turn on the WLAN radio: 1.
  • Page 55 3. If any wireless network is detected, the following window appears on screen. Click the Show drop down menu and select Wireless. 4. Select a wireless network to connect to by clicking a selection, then click Connect. 5. Depending on the settings, you may be asked to enter a WEP key (refer to your Windows online help for more information on setting a wireless network connection).

  • Page 56: Using The Bluetooth ® Feature

    Turning On and Off the Bluetooth Feature 1. Make sure that the RF switch is at the ON position. 2. Right-click the GETAC Utility icon ( system tray and select Quick Bar. Operating Your Computer...

  • Page 57: Connecting To Another Bluetooth Device

    3. The following appears onscreen. To turn on the Bluetooth feature, click the Bluetooth quick button. The Bluetooth indicator ( computer is in the general discoverable and pairable mode after the Bluetooth feature is turned on. 4. To turn off the Bluetooth feature, click the Bluetooth quick button again.
  • Page 58 icon, and then click Add New Connection. 2. Right-click the 3. The Add New Connection Wizard window appears. Select Express Mode (Recommended), and then click Next. Operating Your Computer 2-31...
  • Page 59 4. Select the device to connect to and click Next. 5. Depending on the type of Bluetooth device that you want to connect to, you will need to enter the pertinent information. Sending a File 1. Make sure that the target Bluetooth device is turned on, discoverable and within close range.
  • Page 60 3. In the Wireless File Transfer window, click Add to browse for the file to send. 4. Click the target device from the list, and then click Send to start the transfer procedure. Operating Your Computer 2-33...

  • Page 61: Using The 3G Feature (Optional)

    Using the 3G Feature (Optional) 3G is the third generation of mobile phone standards and technology, after 2G. It is based on the International Telecommunication Union (ITU) family of standards under the International Mobile Telecommunications programme, “IMT-2000”. Services include wide-area wireless voice telephony and broadband wireless data, all in a mobile environment.
  • Page 62 3. Press upward the optical drive release latch ( ) and carefully pull on the ribbon strip ( ) to remove the optical drive from the media bay. 4. Carefully place your computer upside down and locate the SIM card slot.
  • Page 63 Turning On and Off the 3G Feature 1. Make sure that the RF switch is at the ON position. 2. Right-click the GETAC Utility icon ( system tray and select Quick Bar. Operating Your Computer ) located on Windows...
  • Page 64 3. The following appears onscreen. To turn on the 3G feature, click the 3G quick button. The 3G indicator ( 4. To turn off the 3G feature, click the 3G quick button again. You can use the 3G software application to configure 3G connection settings.

  • Page 65: Using The Fingerprint Sensor

    Using the Fingerprint Sensor To start using the fingerprint sensor: 1. Locate and slide open the fingerprint sensor cover. WARNING: To protect the fingerprint sensor, be sure to slide close the cover when not using the fingerprint reader. We shall not be liable for any loss or damage whatsoever resulting from your use of the fingerprint sensor or neglect of fingerprint sensor use, or any data loss resulting from such developments as fingerprint authentication malfunctioning.
  • Page 66 2. Go to Start menu Center. The following screen appears. The computer features the Fingerprint Control Center utility for enrolling your fingers for added security. It contains the following: • Fingerprints – for enrolling or editing fingerprint templates • Settings – for configuring the fingerprint software •...

  • Page 67: Enrolling Fingerprints

    Enrolling Fingerprints To start enrolling your fingerprint(s): 1. Click Fingerprints on the main screen. 2. Then click Initialize. Operating Your Computer 2-40...
  • Page 68 3. The following screen appears. Read carefully the contents of the Welcome screen and then click Next to continue. 4. Follow the onscreen instructions to complete enrolling your fingerprint(s). Operating Your Computer 2-41...

  • Page 69: Changing The Settings

    Changing the Settings To change the settings of your fingerprint software: 1. Click Settings on the main screen. 2. Then click System Settings. Operating Your Computer 2-42...
  • Page 70 3. The following screen appears. Proceed to make the necessary settings to your fingerprint software. 4. Click OK after you have finished with your settings. Operating Your Computer 2-43...

  • Page 71: Managing Power

    Managing Power Your computer operates either on external AC power or on internal battery power. This chapter tells you how you can effectively manage power. To maintain optimal battery performance, it is important that you use the battery in the proper way. The topics in this chapter include: What is an AC adapter How to charge the battery pack...

  • Page 72: Ac Adapter

    AC Adapter CAUTION: The AC adapter is designed for use with your computer only. Connecting the AC adapter to another device can damage the adapter. The AC power cord supplied with your computer is for use in the country where you purchased your computer.

  • Page 73: Battery Pack

    Battery Pack The battery pack is the internal power source for the computer. It is rechargeable using the AC adapter. The operating time of a fully charged battery pack depends on how you are using the computer. When your applications often access peripherals, you will experience a shorter operating time.

  • Page 74: Initializing The Battery Pack

    CAUTION: After the computer has been fully recharged, do not immediately disconnect and reconnect the AC adapter to charge it again. Doing so may damage the battery. NOTE: The battery level may automatically lessen due to the self-discharge process (0.21 % per day), even when the battery pack is fully charged (100 %). This happens no matter if the battery pack is installed in the computer.

  • Page 75: Replacing The Battery Pack

    By Operating System You can check the approximate battery level using the battery meter function of the operating system. To read the battery level in Windows, click the icon on the system tray. By Gas Gauge On the exterior side of the battery pack is a gas gauge for displaying the estimated battery charge.

  • Page 76: Installing A Second Battery Pack (Optional)

    To replace the battery pack, follow these steps: 1. Make sure that the computer is not turned on or connected to AC power. 2. Locate the battery compartment on the left side of the computer. 3. Open the compartment cover by sliding the release latch to the left ( ) then upwards ( ).
  • Page 77 2. Open the media bay cover by sliding the release latch towards the left. 3. Press upwards the optical drive release latch ( ) and carefully pull on the ribbon strip ( ) to remove the optical drive. 4. Slide the second battery pack all the way into the slot. Make sure to observe the correct orientation (the ribbon strip must face outward for future battery pack removal).
  • Page 78 NOTE: To remove the second battery pack, press upwards the battery release latch ( ) and carefully pull on the ribbon strip ( ) to remove the battery pack. On the exterior side of the second battery pack is a gas gauge for displaying the estimated battery charge.

  • Page 79: Battery Low Signals And Actions

    Battery Low Signals and Actions The battery icon changes appearance to display the current state of the battery so that you can see how much charge remains (Windows default setting). When the battery charge is above 25 % the battery icon is green. When the battery charge reaches 25 % a yellow triangle with an exclamation point (!) appears above the green battery icon.

  • Page 80: Power Management

    Power Management Your computer supports ACPI (Advanced Configuration and Power Interface) for power management. The power management feature allows you to reduce the power consumption for energy saving. With an ACPI-compliant operating system such as Windows Vista, power supply to different computer components is controlled on an as-needed basis.

  • Page 81: Hibernation

    Hibernation NOTE: Make sure that the hibernation feature is enabled in the “When I press the power button,” “When I press the sleep button,” and “When I close the lid” of the Power Options System Settings Properties from the Control Panel Windows Vista.

  • Page 82: Power-Saving Tips

    Power-Saving Tips Aside from enabling your computer’s power saving mode (see previous section), you can do your part to maximize the battery’s operating time by following these suggestions. Press the power saving quick button ( saving mode when using battery power. Do not disable Power Management.

  • Page 83: Expanding Your Computer

    Expanding Your Computer You can expand the capabilities of your computer by connecting other peripheral devices. When using a device, be sure to read the instructions accompanying the device together with the relevant section in this chapter. This chapter gives guidelines on installing and using these devices: External monitor Serial device USB device...

  • Page 84: Connecting An External Monitor

    Connecting an External Monitor If you want the benefits of a larger display screen with higher resolution, you can connect an external display monitor to your computer. Follow this procedure to connect an external monitor: 1. Make sure that the computer is not turned on. 2.
  • Page 85 7. You can change display settings through your operating system. See your operating system documentation or online help for specific information. CAUTION: Do not disconnect the external monitor while the computer is in the Sleep mode or Hibernation mode. If no external monitor is connected when the computer resumes, the LCD might not display properly.

  • Page 86: Connecting A Serial Device

    Connecting a Serial Device Your computer has two serial ports for connecting serial devices such as serial mouse or serial communication device (modem). Follow this procedure to connect a serial device: 1. Make sure the “Serial Port COM1/COM2” item is set properly in the BIOS Setup program.

  • Page 87: Connecting A Usb Device

    Connecting a USB Device Your computer has three USB ports for connecting USB devices, such as a digital camera, scanner, printer, modem, and mouse. The USB ports support transfer rates up to 12 MB/s for USB 1.1 devices and 480 MB/s for USB 2.0 devices. To connect a USB device, slide the release latch towards the right to open the port cover and then simply plug the device cable to one of the USB ports.

  • Page 88: Connecting An Ieee 1394 Device

    Connecting an IEEE 1394 Device Your computer has a mini IEEE 1394 port for connecting IEEE 1394 devices that include not only computer peripheral devices such as scanner, printer and high-quality CCD, but also consumer electronic equipment such as DVCAM and VCR. To connect an IEEE 1394 device, prepare an IEEE 1394 cable.

  • Page 89: Using Smart Cards (Optional)

    Using Smart Cards (Optional) Depending on the model, your computer has a smart card slot for additional security feature, providing tamper-proof storage of user and account identity. A smart card is a type of plastic card embedded with a computer chip that stores and transacts data between you (user) and the computer.
  • Page 90 To remove a smart card: 1. Make sure that the third-party smart card software is not accessing the smart card. 2. Pull the card out of the slot. Expanding Your Computer...

  • Page 91: Using Pc Cards

    Using PC Cards Depending on your model, your computer has one or two PC card slots which supports type II card and CardBus specifications. Inserting and Removing a PC Card NOTE: Some PC cards require additional system resources. Before using such PC card, you may have to free other system resources for the PC card.
  • Page 92 To remove a PC card: 1. Double-click on the Safely Remove Hardware Windows Vista taskbar and the Safely Remove Hardware window appears on screen. 2. Select (highlight) the PC card from the list to disable the card. 3. Push the eject button and the card will slide out slightly. 4.

  • Page 93: Using Expresscards (Optional)

    Using ExpressCards (Optional) Depending on the model, your computer has an ExpressCard slot. ExpressCard supports the PCI Express and USB 2.0 serial data interfaces (supporting speeds of up to 2.5 Gbps and 480 Mbps respectively), improving speed in data transfer while conserving power usage. ExpressCard Type The ExpressCard slot can accommodate a 54 mm (ExpressCard/54) or 34 mm (ExpressCard/34) wide ExpressCard.
  • Page 94 2. Slide the ExpressCard, with its label facing up, all the way into the slot until the rear connectors click into place. 3. When a new card is seated, the computer will detect it and try to install the appropriate driver. Follow the on-screen instructions to complete the process.

  • Page 95: Using The Card Reader

    Using the Card Reader NOTE: If your hard disk is divided into several drives, make sure that all drives have been formatted before using the Card Reader. Otherwise, you may encounter problems when using the Card Reader. You can use only storage cards. Your Card Reader does not support cards with I/O (input/output) functions such as a wireless network card or Bluetooth wireless card.
  • Page 96 2. Align the card with its connector pointing to the slot and its label facing down. Slide the card into the slot until it reaches the end. 3. Windows will detect the card and assign it a drive name (typically E). To remove a storage card: 1.

  • Page 97: Using The Port Replicator (Optional)

    Using the Port Replicator (Optional) A port replicator is available as an option. This device eliminates the hassles of having you connect and disconnect the various cables when carrying your computer around and allows a variety of peripherals to be connected including a headphone or microphone, etc.

  • Page 98: System Memory Upgrade

    System Memory Upgrade You can upgrade your computer by changing system memory to a maximum of 4 GB on the two 533/667 MHz DDRII SO-DIMM slots. CAUTION: RAM modules are extremely sensitive to static electricity. There are cases where static electricity generated by the human body has adversely affected such modules.
  • Page 99 4. To install the RAM module, match the module's notched part with the socket's projected part and firmly insert the module into the socket at a 20-degree angle. 5. Then push down until the retaining clips lock the module into position.

  • Page 100: Using Bios Setup

    Using BIOS Setup BIOS Setup Utility is a program for configuring the BIOS (Basic Input/ Output System) settings of the computer. BIOS is a layer of software, called firmware, that translates instructions from other layers of software into instructions that the computer hardware can understand.

  • Page 101: When And How To Use Bios Setup

    When and How to Use BIOS Setup When to Use You need to run BIOS Setup Utility when: You see an error message on the screen requesting you to run BIOS Setup Utility. You want to restore the factory default settings. You want to modify some specific settings according to the hardware.
  • Page 102 The BIOS Setup Utility screen can be divided into four areas: On the top is the menu bar containing the titles of the available menus. Each menu title brings a specific menu. The left column of the menu displays the menu items. The right column of the menu provides more detailed information when a menu item is highlighted.

  • Page 103: Moving Around And Making Selections

    Moving Around and Making Selections You must go through two or three levels to complete the setting for an item. In most cases, there are two levels: menu title and submenu. Use the keyboard to move around and make selections. Keyboard information can be found at the bottom of the screen.

  • Page 104: Information Menu

    Information Menu The Information menu contains the basic configuration information of the system. Using BIOS Setup...

  • Page 105: Main Menu

    Main Menu The Main menu contains the system date and time, as well as USB and wireless LAN settings of the system. System Time sets the system time. System Date sets the system date. Legacy USB Support enables or disables the system’s support for Legacy USB device in DOS mode.

  • Page 106: Advanced Menu

    Advanced Menu The Advanced menu contains the advanced settings as shown next. P1 Function allows you to specify the P1 quick button function. When set at Blackout the P1 quick button allows you to turn off the LCD backlight and LED indicator. When set at Quick Btn the P1 quick button functions as a user customized quick launch key.
  • Page 107 When set at Enhanced and connecting a SATA hard drive is set as Primary on SATA controller in Native mode. When connecting a PATA hard drive is set as Primary on PATA controller in Legacy mode. AHCI Configuration enables support for AHCI (Advanced Host Controller Interface) Native command queuing and Link Power Management.

  • Page 108: Security Menu

    Security Menu The Security menu contains the TPM (Trusted Platform Module) setting. TPM is a component on your computer’s mainboard that is specifically designed to enhance platform security above-and-beyond the capabilities of today’s software by providing a protected space for key operations and other security critical tasks.
  • Page 109 TPM Support enables or disables TPM support (see chapter 6 for details). Current TPM State shows the current TPM state. Change TPM State allows you to select between No Change, Clear, Deactivate & Disable, and Enable & Activate. Using BIOS Setup 5-10...

  • Page 110: Boot Menu

    Boot Menu The Boot menu sets the sequence of the devices to be searched for the operating system. The bootable devices will be automatically detected during POST and shown here, allowing you to set the sequence that the BIOS uses to look for a boot device from which to load the operating system.

  • Page 111: Exit Menu

    Exit Menu The Exit menu displays ways of exiting BIOS Setup Utility. After finishing with your settings, you must save and exit so that the changes can take effect. Exit Saving Changes saves the changes you have made and exits BIOS Setup Utility.

  • Page 112: When And How To Use The System Recovery Feature

    When and How to Use the System Recovery Feature When to Use You need to run System Recovery when: Your computer does not start correctly. Your Windows operating system does not start at all. You want to restore the factory default Windows settings. Starting System Recovery To run System Recovery: 1.
  • Page 113 1. The recovery software is solely the purpose of reinstalling or restoring software associated with the hard disk of this operating GETAC machine. 2. Except the above, no other use is granted hereunder. **************************************** (1)Yes, I agree to the provisions of this agreement and wish to continue.
  • Page 114 5. Your system will start the recovery process and Windows operating system will be re-installed to its default setting. Using BIOS Setup 5-15...

  • Page 115: Using The Tpm And P1 Utility

    Using the TPM and P1 Utility Your computer comes with an added security feature known as the TPM (Trusted Platform Module) – a component on your computer’s mainboard that is specifically designed to enhance platform security above-and-beyond the capabilities of today’s software by providing a protected space for key operations and other security critical tasks.

  • Page 116: Using Trusted Platform Module

    Using TPM (Trusted Platform Module) TPM is a hardware-based security feature that can be used to create and manage computer-generated digital certificates. When combined with security software, the TPM enhances existing network and computer security by enabling features such as file protection capabilities and protected e-mail.

  • Page 117: P1 Quick Launch Key Utility

    Advanced menu (see chapter 5 for details), you can use the quick launch key utility that allows you to define the P1 quick launch key. To start the utility, right-click the GeTAC utility icon ( Quick Buttons Definition on the Windows system tray. The Quick Button Definition window appears as shown next.
  • Page 118 Defining the buttons: The box in the window represents the user-definable button. To assign a program to a button, click the Open icon to pop up the Select a File to Open dialog box as shown next and select the desired program.

  • Page 119: Caring For The Computer

    Caring for the Computer Taking good care of your computer will ensure a trouble-free operation and reduce the risk of damage to your computer. This chapter gives you guidelines covering these areas of maintenance: How to protect the computer What to note when using and storing the computer How to clean the computer What to note when using the battery pack What to note when traveling with the computer...

  • Page 120: Protecting The Computer

    Protecting the Computer To safeguard the integrity of your computer data as well as the computer itself, you can protect the computer in several ways as described in this section. Using the Windows Security Center Windows Security Center protects your computer against intrusion. Caring for the Computer...

  • Page 121: Using The Cable Lock

    Windows Security Center alerts you to take action on the following security essentials: Windows Firewall Windows Update Malware Protection (anti-virus, anti-spyware) Others (Internet security, user account control) For detailed information on Windows Security Center, see Windows’ Help. Using the Cable Lock You can use a Kensington-type cable lock to protect your computer against theft.

  • Page 122: Taking Care Of The Computer

    Taking Care of the Computer Location Guidelines For optimal performance, use the computer where the recommended temperature is between 0 °C (32 °F) and 55 °C (131 °F) – actual operating temperature depending on product specifications. Avoid placing the computer in a location subject to high humidity, extreme temperatures, mechanical vibration, direct sunlight, or heavy dust.

  • Page 123: Cleaning Guidelines

    Cleaning Guidelines Never clean the computer with its power on. Use a soft cloth moistened with water or a non-alkaline detergent to wipe the exterior of the computer. Gently wipe the display with a soft, lint-free cloth. Do not use alcohol or detergent on the display.

  • Page 124: Touchscreen Guidelines

    It is recommended that you charge the battery pack with the computer’s power off. To maintain the battery pack’s operating efficiency, store it in a cool dark place removed from the computer and with 30 % ~ 40 % charge remaining.
  • Page 125 Turn off the computer power when cleaning the display. Cleaning the display with the power on may cause improper operation. Use the touchscreen within the intended area only. The display area and touchscreen operating area is the same. Using it beyond the allowed area may cause damage to the display and result in improper operation.

  • Page 126: When Traveling

    When Traveling Before traveling with your computer, make a backup of your hard disk data into flash disks or other storage devices. As an added precaution, bring along an extra copy of your important data. Make sure that the battery pack is fully charged. Make sure that the computer is turned off and the top cover is securely closed.

  • Page 127: Troubleshooting

    Troubleshooting Computer problems can be caused by hardware, software, or both. When you encounter any problem, it might be a typical problem that can easily be solved. This chapter tells you what actions to take when solving common computer problems. It is divided into three sections: Preliminary checklist Solving common problems Resetting the computer...

  • Page 128: Preliminary Checklist

    Preliminary Checklist Here are helpful hints to follow before you take further actions when you encounter any problem: Try to isolate which part of the computer is causing the problem. Make sure that you turn on all peripheral devices before turning on the computer.

  • Page 129: Solving Common Problems

    Solving Common Problems For easy reference, the problems are divided into these categories. Problem Type Battery Problems Bluetooth Wireless Transmission Problems Display Problems ExpressCard Problems Hardware Device Problems Hard Disk Drive Problems Keyboard, Mouse, and Touchpad Problems LAN Problems WLAN Problems Modem Problems Optical Drive Problems PC Card Problems...

  • Page 130: Battery Problems

    Battery Problems The battery does not charge (Battery Charge indicator does not light amber). Make sure that the AC adapter is properly connected. Make sure that the battery is not too hot or cold. Allow time for the battery pack to return to room temperature. Make sure that the battery pack is installed correctly.

  • Page 131: Display Problems

    Make sure that both devices are compatible. Display Problems Nothing appears on the screen. During operation, the screen may automatically turn off as a result of power management. Press any key to see if the screen comes back. The brightness level might be too low. Increase brightness by pressing the hot key.

  • Page 132: Expresscard Problems

    ExpressCard Problems The ExpressCard does not work. Make sure that the ExpressCard is correctly seated. If the card requires an IRQ (Interrupt ReQuest), make sure that there is one available. The ExpressCard stops communicating properly. The application may have been reset when the computer is turned off or in Sleep mode.

  • Page 133: Keyboard, Mouse, And Touchpad Problems

    The hard disk drive in-use indicator glows without blinking. The data files stored on the hard disk drive may be fragmented. Use a tool such as Window’s Disk Defragmenter to defragment the files. Keyboard, Mouse, and Touchpad Problems The keyboard does not respond. Try connecting an external keyboard.

  • Page 134: Wlan Problems

    WLAN Problems I cannot use the WLAN feature. Make sure that the mini PCI-E WLAN card is correctly installed. Make sure that the WLAN feature is turned on. Transmission quality is poor. Your computer may be in an out-of-range situation. Move your computer closer to the Access Point or another WLAN device it is associated with.

  • Page 135: Modem Problems

    If the operating radio channel is in poor quality, change the Access Point and all the wireless station(s) within the BSSID to another radio channel. Your computer may be in an out-of-range situation. Move your computer closer to the Access Point it is associated with. Make sure that your computer is configured with the same security option (encryption) to the Access Point.

  • Page 136: Pc Card Problems

    Make sure that the disc is not dirty. Clean the disc with a disc cleaning kit, available in most computer stores. Make sure that the computer supports the disc or the files contained. You cannot eject a disc. The disc is not properly seated in the drive. Manually release the disc following the method described next: Turn off the computer.

  • Page 137: Power Management Problems

    If the card requires an IRQ (Interrupt ReQuest), make sure that there is one available. The PC card stops communicating properly. The application may have been reset when the computer is turned off or in Sleep mode. Exit and restart the application. Power Management Problems The computer does not enter Sleep or Hibernation mode automatically.

  • Page 138: Software Problems

    Software Problems An application program does not work correctly. Make sure that the software is correctly installed. If an error message appears on the screen, consult the software program’s documentation for further information. If you are sure the operation has stop, reset the computer. (See “Resetting the Computer”...

  • Page 139: Startup Problems

    Startup Problems When you turn on the computer, it does not respond and the Power Indicator does not light green. If you are using an external AC power, make sure that the AC adapter is correctly and securely connected. If so, make sure that the electrical outlet works properly.

  • Page 140: Resetting The Computer

    Resetting the Computer You may have to reset (reboot) your computer on some occasions when an error occurs and the program you are using hangs up. If the computer operation seems to hang up, first wait. It is possible that the computer is processing data.

  • Page 141: Appendix A Specifications

    Specifications NOTE: Specifications are subject to change without any prior notice. Parts Intel® Core™ 2 Duo Merom processor LV L7300/LV7500 800 MHz FSB (Front Side Bus), 1.4/1.6 GHz, 4 MB L2 cache thermal specifications 17 W Chipset NorthBridge Intel® GM965, dual channel support SouthBridge Intel®...
  • Page 142 Parts Storage device Hard disk drive SATA interface, 2.5-inch diameter (9.5 mm height), 5400 rpm support, G-sensor, shock-mounted, user-removable, solid-state disk (option), automotive hard disk drive (option), low temperature – 4 Optical drive DVD Combo / DVD Dual / Super-Multi Card slots Card Reader 4-in-1 (MMC/SD/MS/MS PRO card) module PCMCIA CardBus Type II ×...

  • Page 143: Appendix B Regulatory Information

    Regulatory Information This appendix provides regulatory statements and safety notices on your computer. NOTE: Marking labels located on the exterior of your computer indicate the regulations that your model complies with. Please check the marking labels and refer to the corresponding statements in this appendix.

  • Page 144: On The Use Of The System

    On the Use of the System Class B Regulations Federal Communications Commission Radio Frequency Interference Statement NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.

  • Page 145: Safety Notices

    Canada Canadian Department of Communications Radio Interference Regulations Class B Compliance Notice This Class B digital apparatus meets all requirements of the Canada Interference-Causing equipment regulations. Cet appareil numérique de Classe B respecte toutes les exigences du Règlement Canadien sur le matériel brouileur. This digital apparatus does not exceed the Class B limits for radio noise emissions from digital apparatus set out in the Radio Interference Regulations of the Canadian Department of Communications.
  • Page 146 ENGLISH CAUTION: Danger of explosion if battery is incorrectly replaced. Replace only with the same or equivalent type recommended by the equipment manufacturer. Discard used batteries according to manufacturer's instructions. DEUTSCH VORSICHT: Explosionsgefahr bei unsachgemäßem Austausch der Batterie. Ersatz nur durch denselben oder einen vom Hersteller empfohlenen gleich-wertigen Typ.

  • Page 147: About The Modem

    About the Modem Caution Never install telephone wiring during a lightning storm. Never install telephone jacks in wet locations unless the jack is specifically designed for wet locations. Never touch non-insulated telephone wires or terminals unless the telephone line has been disconnected at the network interface. Use caution when installing or modifying telephone lines.

  • Page 148: On The Use Of The Rf Device

    On the Use of the RF Device NOTE: The information in this section applies to models with the wireless LAN module. USA and Canada Safety Requirements and Notices IMPORTANT NOTE: To comply with FCC RF exposure compliance requirements, the antenna used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter.
  • Page 149 The use of wireless devices in hospitals is restricted to the limits set forth by each hospital. Antenna use: In order to comply with FCC RF exposure limits, low gain integrated antennas should be located at a minimum distance of 20 cm (8 inches) or more from the body of all persons.
  • Page 150 EMC Requirements This device uses, generates and radiates radio frequency energy. The radio frequency energy produced by this device is well below the maximum exposure allowed by the Federal Communications Commission (FCC). This device complies with the limits for a Class B digital device pursuant to Part 15 subpart C of the FCC Rules and Regulations.

  • Page 151: European Union Ce Marking And Compliance Notices

    Canada Radio Frequency Interference Requirements To prevent radio interference to the licensed service, this device is intended to be operated indoors and away from windows to provide maximum shielding. Equipment (or its transmit antenna) that is installed outdoors is subject to licensing. Pour empêcher que cet appareil cause du brouillage au service faisant l'objet d'une licence, il doit être utilisé...
  • Page 152 Greek To προϊόν αυτό πληροί τις προβλέψεις της Ευρωπαϊκής Οδηγίας 1999/5/EC. Icelandic Þessi vara stenst reglugerð Evrópska Efnahags Bandalagsins númer 1999/5/EC. Italian Questo prodotto è conforme alla Direttiva Europea 1999/5/EC. Norwegian Dette produktet er i henhold til bestemmelsene i det europeiske direktivet 1999/5/EC.
  • Page 153 The European variant is intended for use throughout the European Economic Area. However, authorization for use is further restricted in particular countries or regions within countries, as follows: General European standards dictate maximum radiated transmit power of 100 mW Effective Isotropic Radiated Power (EIRP) and the frequency range 2400 –...
  • Page 154 Departments in Which the Wireless LAN Module’s Maximum EIRP Not Shown in the Previous Table Frequency Ranges (MHz) 2400 – 2446.5 2446.5 – 2483.5 Turning Off the Wireless LAN Radio NOTE: Turning the wireless LAN radio off is not the same as disabling the wireless LAN card.

Table of Contents

Save PDF
