After Use Care

Cutting System

• Never place any part of body under cutting blade shield when cutting blade is
rotating.
• Do not allow bystanders to come near machine when cutting blade is rotating.
• Always stay on machine when performing this opeartion
• Never attempt to clean cutting system with cutting blade shield open. Stones or
rocks can be thrown and cause damage to surrounding properties or persons.
• Turn cutting rotary clutch to [ON] only when cleaning. Keep it in [OFF] position
all the other times.
5355M-0510-010E
6. Move cutting rotary clutch lever to [ON] to rotate cutting blade to clean.
7. When cleaning is done, move cutting rotary clutch lever to [OFF] to stop cutting blade.
8. Move cutting height adjust lever to [150].
9. Turn throttle lever to [
10. Stop machine and remove hose.
NOTE
• Do not set cutting height too low. It may hit ground.
Maintenance
Hose Connection
(slow)] to lower engine speed.
1. Park machine.
2. Set cutting height to about 50mm.
3. Connect hose to hose connection. Run
water through hose.
4. Start engine.
5. Turn throttle lever to [
engine speed.
-75-
5
(fast)] to raise
